SPECIFICATIONS

D General
• Frequency coverage
U.S.A. Transmit
Receive
S. America Transmit
Receive
Europe, Tx/Rx
Taiwan
Italy Transmit
Receive
Asia Transmit
Receive
• Mode
• No. of memory channels : 232
• Tuning steps
• Frequency stability
• Power supply requirement : 13.8 V DC ±15%
82
:
1
144–148, 430–450*
2 1
118–174* , 430–450*
144–148, 430–440
2 3
118–174* , 400–530*
144–146, 430–440
144–148, 430–440
2 3
136–174* , 400–530*
144–148, 430–440
2
136–174* , 430–440
1
* Specifications guaranteed 440–450 MHz.
2
* Specifications guaranteed 144–148 MHz.
3
* Specifications guaranteed 430–440 MHz.
: FM,
AM
(118–135.995; Rx only)
(incl. 12 scan edges, 10 log,
10 repeater and 2 call)
: 5, 10, 12.5, 15, 20, 25, 30 and 50
kHz
: ±10 ppm
(–10°C to +60°C; +14°F to +140°F)
(negative ground)
• Current drain
Transmit
(Unit: MHz)
Receive
* 8.0 A for Taiwan version.
• Antenna connector
• Data connector
• External video input
• Dimensions (projections not included):
Controller
Main unit
• Weight (approx.)
D Transmitter
• Modulation system
• Output power
* 25 W (High), 15 W (Mid-H) for both VHF and UHF for Taiwan ver-
sion.
• Spurious emissions
• Microphone connector
:
(VHF/UHF; at 13.8 V DC)
max. power 12.0 A/11.0 A*
standby 1.2 A
max. audio 1.8 A
: SO-239 (50 Ω)
: Mini DIN 6-pin
: PHONO [RCA (75 Ω)]
140(W) 70(H) 34(D) mm
1 3
5 ⁄ (W) 2 ⁄ (H) 1
2 4
140(W) 40(H) 165.8(D) mm
1 9
5 ⁄ (W) 1 ⁄ (H) 6
2 16
: Controller 290 g; 10.2 oz
Main unit 1.15 kg; 2 lb 9 oz
: Variable reactance
: High* 50 W/35 W
(VHF/UHF)
Mid-H* 20 W
Mid-L 10 W
Low 5 W
: –60 dB
: 8-pin modular (600 Ω)
11
⁄ (D) in
32
17
⁄ (D) in
32
(approx.)
(approx.)
(approx.)
