o FREQUENCY READOUT
Shows the operating frequency, memory name, etc.
!0 PRIORITY WATCH INDICATOR (p. 48)
Appears when priority watch is in use.
!1 TONE INDICATORS (pgs. 26, 50, 52)
"T" appears when the subaudible tone encoder is in use;
"T SQL ì" appears during pocket beep operation and
"T SQL" appears when the tone squelch function is acti-
vated.
!2 DUPLEX INDICATORS (p. 26)
Appear when semi-duplex operation (repeater operation)
is in use.
• "DUP –" appears when minus duplex is selected; "DUP" appears
when plus duplex is selected.
!3 OUTPUT POWER INDICATORS (p. 25)
"HI" appears when high output power is selected.
"MID-HI" appears when mid high output power is se-
lected
"MID-LO" appears when mid low output power is se-
lected
"LO" appears when low output power is selected
PANEL DESCRIPTION
!4 MAIN BAND INDICATOR (p. 18)
"Q" appears above the frequency which is selected
as the main band.
"^" appears when the sub band access function is
in use.
• This function can be used via the HM-98 and HM-90.
!5 AM/FM NARROW MODE INDICATOR (p. 74)
"AM" appears when AM mode is selected.
• AM mode is available for the U.S.A. and S. America versions
only.
"NAR" appears when FM narrow mode is selected.
• FM narrow mode is available for the VHF band of the Europe
and Italy versions only.
!6 MUTE INDICATOR (pgs. 24, 65)
Both band's indicators appear when the mute function is
in use.
• This function can be used via the HM-98 and HM-90.
Sub band's indicator appears when the sub band mute
function is activated.
