r MONITOR/LOW POWER MENU [MONI (LOW)]
Push to toggle the monitor function ON and OFF. (p. 24)
Push for 2 sec. to change the output power selection. (p.
25)
• Low (LO), mid-low (MID-LO), mid-high (MID-HI) and high (HI)
powers are available.
t MAIN BAND/MEMORY EDIT MENU [MAIN (EDIT)]
Push to select the main band. (p. 18)
Push for 2 sec. to enter the edit screen. (pgs. 29, 30, 37,
46, 51)
y TONE/DUPLEX MENU [TON (DUP)]
Push to activate the following functions in order.
• Subaudible tone encoder—"T" appears. (p. 26)
• Pocket beep—"T SQLì" appears. (p. 52)
• Tone squelch—"T SQL" appears. (p. 50)
• No tone operation—no indicator appears.
Push for 2 sec. to select semi-duplex or simplex opera-
tion. (p. 26)
• "DUP–" appears during minus duplex operation, "DUP" ap-
pears during plus duplex operation and no indicator appears
during simplex operation.
PANEL DESCRIPTION
u SELECT MEMORY WRITE/MEMORY WRITE MENU
[S.MW (MW)]
Push to select the desired memory channel number to
be programmed. (p. 32)
Push for 2 sec. to program a memory channel or call
channel while in VFO mode. (p. 32)
Push for 2 sec. to transfer a memory channel, call chan-
nel or scratch pad memory contents into the VFO when
not in VFO mode. (p. 33)
i DTMF MENU [DTMF]
Push to toggle the DTMF memory ON and OFF. (p. 55)
Push for 2 sec. to enter the DTMF memory screen. (p.
54)
o DISPLAY/SET MODE MENU [DISP (SET)]
Push to enter the display set mode screen. (p. 68)
Push for 2 sec. to enter the set mode screen.
