5.4 Stylus falls off a frame during reading.
Is the R-direction movement
smooth?
Yes
Is the Z-direction movement
smooth?
Yes
Adjust Frame force or set
value.
5.5 After reading frame, "transmitting" message appears, but the data isn't transmitted to the edging
body.
Is the cable connected
properly?
Yes
Is the cable broken?
Yes
Is the port Configuration
correct?
Yes
Replace the Main Board of
Frame Reader referring to
page 43
Clean the slide with compressed
air or adjust R-Motor Ass'y gap
No
referring to page 15.
Clean the slide with compressed
air or adjust Z Updown Ass'y gap
No
referring to Maintenance book.
Connect again to the proper port.
No
Replace the RS-232C cable.
No
Set the port Configuration properly.
No
EXCELON
I
Trouble shooting manual -6
