Huvitz EXCELON Service Manual page 69

R-2
R-1
Ref No. Name of Part
R FRAME ASSY
R ― 1 TRACER PCB
R ― 2 LEFT PI SENSOR
R ― 3 RIGHT PI SENSOR
R ― 4 ROTATE BASE ASSY
R ― 4 ― 1 R PI SENSOR
R ― 4 ― 2 ROTATION STEP MOTOR
S-1
Ref No. Name of Part
S ROTATOR ASSY
S ― 1 ROTATE PCB1
S ― 2 Z UPDOWN ASSY
S ― 2 ― 1 STYLUS SHAFT
S ― 2 ― 2 STYLUS TIP
S ― 2 ― 3 PRECISION SLIDE
S ― 2 ― 4 Z ENC RACK
S ― 2 ― 5 Z SHAFT PLATE
S ― 2 ― 6 TENSION SPRING
[M. FRAME ASSY]
[S. ROTATOR ASSY]
R-3
R-4
[M-4. ROTATE BASE ASSY]
Code of Part
H0MASSY003-AA
61700H00001-A MAIN CONTROL B/D FRM102, 255X130
H0EHAR3004-AS
H0EHAR3005-AS
H0MASSY014-AA
H0EHAR6003-AS W/D CABLE
H0EHAR3003-AS W/D CABLE
S-2
Code of Part
H0MASSY021-AA
61600H00001-A MOTOR CONTROL B/D FRD-100,50X54
1210A00H006-A
1240MP0H002-A
3012A000002-A
1320A00H002-A
1200MP0H008-A
3008A000004-A
R-4-2
R-4-1
Description
S-2-2
S-2-1
S-2-3
S-2-6
S-2-5
S-2-4
[S-2. Z UPDOWN ASSY]
Description
EXCELON
Unit Price(U$)
-
30
5
5
240
5
40
Unit Price(U$)
5
10
10
105
30
30
2
Part Price List V - 67
