Huvitz CME-9000 Service Manual
  1. Manuals
  2. Brands
  3. Huvitz Manuals
  4. Laboratory Equipment
  5. CME-9000
  6. Service manual

Huvitz CME-9000 Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
PRODUCT
Auto Lens Edger
MODEL
CME-9000
REVISON

Table of Contents

DOC No.
SCS-I-9ME-091
DATE
2013.12.25
REVISION DATE
USE
2013.12.25
PREPARE
REVIEW
CONFIRM

Advertisement

loading
Need help?

Need help?

Do you have a question about the CME-9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huvitz CME-9000

Summary of Contents for Huvitz CME-9000

  • Page 1: Table Of Contents

    SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 Table of Contents 1. How to check SW version 2. Replacing Board 3. Replacing Cover 4. Sensor Position 5. Adjusting Clamp Power 6.

  • Page 2: How To Check Sw Version

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. How to check SW version...
  • Page 3 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. Checking SW Version 1) Select menu 2) Select User menu 3) Check SW version (GUI, MOTOR)

  • Page 4: Replacing Board

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 2. Replacing Board...
  • Page 5 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. Open Cover GUI Board Motor Board Power Board 1) Loosen 2 bolts 2) Open the front cover...
  • Page 6 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 2. Replace GUI board FRAM 1) Disconnect cables 2) Loosen 4 screws 3) Use original FRAM to use original setup data Recommend to take a picture of setup data.(User...
  • Page 7 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Replace Motor board and Power board Motor board Power board 1) Loosen 4 screws / 2) Replace board Disconnect cables for each...

  • Page 8: Replacing Cover

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Replacing Cover...
  • Page 9 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. Open Cover GUI Board and keypad board Motor Board Power Board 1) Loosen 2 bolts 2) Open the front cover...
  • Page 10 REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 2. Remove GUI board and Keypad 3) Disconnect keypad 2 cables 4) Loosen 5 screws and remove Keypad board 1) Disconnect cables 5) Remove keypad 2) Loosen 4 screws of Some cables are tied to cover.
  • Page 11 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Remove front cover 1) To replace front cover, 3) Pull the bar on 2) Push the bar with remove a connecting bar...

  • Page 12: Sensor Position

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Sensor Position...
  • Page 13 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. PI Sensor Y Top PI R PI Y Bottom PI...
  • Page 14 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. Limit Switch X Limit Y Bottom Limit...

  • Page 15: Adjusting Clamp Power

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Adjusting Clamp Power...
  • Page 16 SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 Adjust Clamp Open/Close Power 1) Select menu 2) Select Engineer menu 3) Select Clamp power Adjust Close/Open Power Adjust Clamp Processing Power...

  • Page 17: Adjusting Wheel Position

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Adjusting Wheel Position...
  • Page 18 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 Adjust Wheel position 1) Select menu 2) Select Engineer menu 3) Adjust wheel position (0 position: right side)

  • Page 19: Adjusting Size And Margin

    DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 3. Adjusting Size and Margin...
  • Page 20 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 1. Adjust Size 1) Select menu 2) Select Engineer menu 3) Adjust lens size. You can adjust size for different lens material (PL, PC…)
  • Page 21 DOC No. SCS-I-9ME-091 PREPARE REVIEW CONFIRM SERVICE MANUAL PRODUCT Auto Lens Edger DATE 2013.12.25 MODEL CME-9000 REVISION DATE REVISON 2013.12.25 2. Adjust Margin 1) Select menu 2) Select Engineer menu 3) Adjust margin (unit: radius)
