  • Page 2 Excelon XD/XQ Operator’s Manual Operator’s Manual Excelon XD/XQ...

  • Page 3: Important Notice

    HUVITZ reserves the right to make changes in its products or product specifications at any time without prior notice and is not required to update this documentation to reflect such changes.

  • Page 4: Table Of Contents

    Excelon XD/XQ Operator’s Manual Contents IMPORTANT NOTICE ..................2 1. Introduction ....................6 1.1 System Configuration ................6 1.2 Main Features ..................6 1.3 Classification ................... 7 2. Safety Information ..................8 2.1 Introduction ..................... 8 2.2 Safety Symbols ..................9 2.3 Environment factors ................
  • Page 5 Excelon XD/XQ Operator’s Manual 5.2.6 Digital Pattern ................. 38 5.2.7 Retouch Mode ................. 43 5.2.8 Menu Bar ..................46 5.2.9 Menu Dialog Box ................47 5.3 Hole Editor Screen(XD) ............... 51 5.3.1 Layout of Hole Editor ..............51 5.3.2 Add Hole ..................53 5.3.3 Change Hole Type ................
  • Page 6 Excelon XD/XQ Operator’s Manual 6.1.4 Hole Editor Default (XD) ..............87 6.2 Frame Fitting ..................90 6.3 Adjustment .................... 92 6.3.1 Size Adjustment ................92 6.3.2 Margin Adjustment ................93 6.3.3 Axis Adjustment ................94 6.3.4 Bevel Adjustment ................95 6.3.5 Grooving Adjustment ...............

  • Page 7: Introduction

    Excelon XD/XQ Operator’s Manual 1. Introduction 1.1 System Configuration • Edger (HPE-7000/HPE-7000ND) + Auto Blocker (CAB-4000) • Edger (HPE-7000/HPE-7000ND) + Frame Reader (CFR-4000) 1.2 Main Features • All the finishing processes, tracing to edging, are fully operated with the advanced...

  • Page 8: Classification

    Excelon XD/XQ Operator’s Manual User Interface are harmonized to offer the maximum convenience for everyday • The “Digital Pattern Layout” modifies the lens shape in left/right, top/bottom as well as circumference and optimizes the fitting challenge for Rimless and Semi- Rimless •...

  • Page 9: Safety Information

    Excelon XD/XQ Operator’s Manual 2. Safety Information 2.1 Introduction Safety is everyone’s responsibility. The safe use of this equipment is largely dependent upon the installer, user, operator, and maintainer. It is imperative that personnel study and become familiar with this entire manual before attempting to install, use, clean, service or adjust this equipment and any associated accessories.

  • Page 10: Safety Symbols

    Excelon XD/XQ Operator’s Manual 2.2 Safety Symbols The International Electro technical Commission (IEC) has established a set of symbols for medical electronic equipment, which classify a connection or warn of any potential hazard. The classifications and symbol s are shown below.

  • Page 11: Environment Factors

    Excelon XD/XQ Operator’s Manual 2.3 Environment factors Avoid the following environments for operation or storage: Where the equipment is exposed to water vapor. Don’t operate the equipment with a wet hand. Where the temperature changes extremely. - Operation Temperature: 10 ~ 40C (Humidity : 50 ~ 80%) - Storage Temperature : -20 ~ 85C (Humidity : 50 ~ 80%)

  • Page 12: Safety Precaution

    Excelon XD/XQ Operator’s Manual Be careful not to be inserted dust, especially, metal Be careful not to close the fan located on the lateral or backside of the equipment. Pull out the power cord with holding the plug, not the cord.
  • Page 13 The equipment must be operated only by, or under direct supervision of a properly trained and qualified person. The service technician of Huvitz or the technician authorized by Huvitz may only carry out modifications of this equipment. Customer maintenance of this equipment may only be performed as stated in the User’s Manual and Service Manual.
  • Page 14 Excelon XD/XQ Operator’s Manual damage to a cable connector(s) or receptacle(s), let the damage(s) be repaired by an authorized service technician. (12) Please do not pull on any cable. Always hold on to the plug when disconnecting cables. (13) Before every operation, visually check the equipment for exterior mechanical damage(s) and for proper function.
  • Page 15 Excelon XD/XQ Operator’s Manual WARNING • Be sure that any part of human body is not interfered with the edging wheel during the operation. Otherwise, the person may be seriously hurt. • Edging room cover should be fully closed during the lens finishing process. If the lens is broken during the process, the broken pieces of lens may cause the damage to the person.
  • Page 16 Excelon XD/XQ Operator’s Manual WARNING • Do not disassemble the product without the proper training. It may cause the electric shock, serious hurt during the operation or cause the malfunction of the product. • Be sure the material of lens is matched with the job options selected in the display before starting the edging mode.
  • Page 17 Excelon XD/XQ Operator’s Manual CAUTION • When moving the equipment, first fix the stage and check whether the power supply is off. Then, two or more persons should lift the bottom of the product with both hands. • In case of setting down the equipment, make sure not to be interfered with the obstacles.
  • Page 18 Excelon XD/XQ Operator’s Manual - Other end IEC 60320 C13 max. 3 m long For 200-240 Vac use - Plug end - Cable H05VV-F 3G, min. 1.0 mm2 - Other end (with appliance coupler connected to unit IEC 60320 C13),...

  • Page 19: System Configurations

    Excelon XD/XQ Operator’s Manual 3. System Configurations 3.1 Main Body Front View Display window (Touch Screen) Edging Room Cover (Auto) Operating Buttons Edging Room Drill(XD) Lens Feeler Clamp Main Wheel Wheel for Safety Beveling and Grooving 휠 Top View Main Switch...
  • Page 20 Excelon XD/XQ Operator’s Manual For Edging Polycarbonate...

  • Page 21: Standard Accessory (Tool Box)

    Excelon XD/XQ Operator’s Manual 3.4 Standard Accessory (Tool Box) Lens Adaptor Drill Bit(XD) LEAP-Ⅲ Tape Wrench(XD) Lens Adaptor Remover Fuse(250V,10A) Standard Frame Standard Pattern Pattern Holder Hexagonal Wrench Set Standard JIG for Edger Dressing Sticks Feeler Tips Fixing Bracket NOTE •...

  • Page 22: Installation Procedure

    Excelon XD/XQ Operator’s Manual 4. Installation Procedure ① Remove the shock-absorbing material from the packing box and pull out the Edger carefully. ② Unfasten the screw at the Edger Front Cover and lift it open. ③ Remove the Fixing materials (bracket, sponge, tape).
  • Page 23 Excelon XD/XQ Operator’s Manual CAUTION • If the initialization process fails, check the following. - Check drill fixing sponge removed(XD) - Check carriage fixing sponge removed (Right and Left) - Check carriage fixing bracket removed - Check feeler fixing tape removed •...

  • Page 24: Operation

    Excelon XD/XQ Operator’s Manual 5. Operation 5.1 Display and Control Buttons Touch Screen CLAMP START STOP WINDOW CLAMP CLAMP Open/Close Clamp (Lens Position Left/Right) START Start Edging STOP Stop Edging WINDOW Open/Close Edging Room Window ! NOTE • Clamp Buttons in the Left and Right provide the exactly same function. They are provided for the convenience to press the button by the bare hand without holding the lens.

  • Page 25: Main Screen

    Excelon XD/XQ Operator’s Manual 5.2 Main Screen 5.2.1 Layout of main screen Menu bar Frame Information Job List Tab Edging Options Layout Options Function Buttons ! NOTE XQ model edging options (Drilling options are not displayed)

  • Page 26: Job List Tab

    Excelon XD/XQ Operator’s Manual 5.2.2 Job List Tab Finished Job Current Job Edging Job Page Information (Current Number/Total) All jobs in the edger displayed on the tabbed menu and 5 jobs are displayed in a page. To select a job, just press the tab.

  • Page 27: Frame Information

    Excelon XD/XQ Operator’s Manual 5.2.3 Frame Information Min lens diameter Right side selected Frame curve Bridge Size Lens Adaptor Frame type Grid show/hide Touch lock/release If a job selected, frame shape is displayed on the screen in actual measurement with the frame information.
  • Page 28 Excelon XD/XQ Operator’s Manual NOTE • Changing bridge size display option, FPD can be displayed instead of bridge size(Default option is bridge size). • FPD : Distance between the frame centers (boxing centers) • In case of Two Eye Tracing, the value of FPD will be automatically transmitted and displayed.

  • Page 29: Layout Options

    Excelon XD/XQ Operator’s Manual 5.2.4 Layout Options These icons are used for changing layout options. Touch the icon to change the option. (1) Lens Type Single Focus Bi-focal (flat top) Bi-focal (round top) (Far Vision) (Near Vision) (Near Vision) (2) Blocking Mode...
  • Page 30 Excelon XD/XQ Operator’s Manual Execute Right/Left Cancel Right/Left Synchronization Synchronization (6) Frame Change Mode Frame Change Cancel Frame Change NOTE • In case of executing the options for Bi-Focal(Near Vision, ), Near Vision Shape will be displayed on the LCD screen. If the near vision area diameter is entered, user can see the frame shape similar to the actual lens shape and can check the interference easily.
  • Page 31 Excelon XD/XQ Operator’s Manual • The exact meaning of the mix height and the box height is as following: FPD based OH Mix Height Box Height • It is so important to measure the optical height of the patient precisely when edging a progressive lens.
  • Page 32 Excelon XD/XQ Operator’s Manual NOTE • Bifocal Lens Layout (1) Change Lens type option to bifocal mode(Select either “Bifocal(flat top)” mode or “Bifocal(round top)” mode). (2) Adjust near vision area size. (3) Input near vision PD and OH(Use either “Box-Height” type or “Mix-Height”...
  • Page 33 Excelon XD/XQ Operator’s Manual...

  • Page 34: Edging Options

    Excelon XD/XQ Operator’s Manual 5.2.5 Edging Options These icons are used for changing edging options. Press the icon to change the option. (1) Edging Type Beveling Flat Edging Grooving (2) Size Adjustment (3) Clamping Pressure Adjustment (4) Safety Mode Normal Mode...
  • Page 35 Excelon XD/XQ Operator’s Manual (7) Lens Material Trivex Plastic (CR39) Polycarbonate HI-Index Glass (8) Bevel/Groove Position Front Side % Front Side mm Rear Side mm Base Curve (9) Main Edging Option Icon (Polishing, Safety Beveling, Groove Width/Depth) Polishing On/Off Front...
  • Page 36 Excelon XD/XQ Operator’s Manual NOTE • According to the Edging Options, Beveling and Grooving position can be selected independently. ☞ Ratio (%) from the Front side of the lens ☞ Distance (㎜) from the Front side of the lens ☞...
  • Page 37 Excelon XD/XQ Operator’s Manual by the 50% of the thickness at the thin position. Base Curve Base Base [Base curve mode] Curve Curve (+) lens (-) lens • In the base curve mode, base curves of (+) lenses and (-) lenses exist the opposite side of each of them.
  • Page 38 Excelon XD/XQ Operator’s Manual CAUTION • Be sure to carry out the Edging Process in Safety Mode ( ) in case the lens may be broken or the axis may be tilted during the edging process. • Select “Safety Mode” or adjust clamp pressure in case the lens may be broken.

  • Page 39: Digital Pattern

    Excelon XD/XQ Operator’s Manual 5.2.6 Digital Pattern The “Digital Pattern” modifies the lens shape in left/right, top/bottom as well as rotation and optimizes the fitting for Rimless and Semi-Rimless. To use Digital Pattern, press the digital pattern button( ) on the function button area.
  • Page 40 Excelon XD/XQ Operator’s Manual Left/Right Enlargement Top/Bottom Enlargement Reduction...
  • Page 41 Excelon XD/XQ Operator’s Manual (2) Rotation To rotate lens shape, press and drag Rotation Stick. Lens shape can be rotated clockwise or counterclockwise. Rotation Stick Rotate 20 degrees (Clockwise, Right Lens) (3) Near Vision Area Enlargement/Reduction This function only applied to near vision area.
  • Page 42 Excelon XD/XQ Operator’s Manual Near Vision Area Enlargement (4) Reset Recover original lens shape. (Restore the first frame shape received from frame reader or auto blocker) Reset (5) Exit Finish Digital Pattern function. When exit dialog box popped up, select “Yes” to save modified lens shape.
  • Page 43 Excelon XD/XQ Operator’s Manual Exit NOTE • For the half-framed lens or the rimless lens, the digital pattern provides the convenient reformation. The redesign of the frame shape could be done easily using the digital pattern. • For the bi-focal lens or the progressive, the digital pattern makes the near vision area included within the frame.

  • Page 44: Retouch Mode

    Excelon XD/XQ Operator’s Manual 5.2.7 Retouch Mode If the finished lens is too large, it is possible to readjust lens size in the retouch mode,. After finishing, press the Retouch icon and then setup retouch options. Press the [START] button to start retouching.
  • Page 45 Excelon XD/XQ Operator’s Manual (2) Activate/Cancel Polishing The operator can activate polishing, even if the lens has not been polished originally. Activate Polishing Cancel Polishing (3) Activate Grooving Even if the lens has been flat edged, the operator can add grooving by entering grooving depth value.
  • Page 46 Excelon XD/XQ Operator’s Manual NOTE • Be sure not to remove the Lens Adapter to activate the Retouch Mode. • Be sure not to change any edging option before entering Retouch Mode. • The recommended Retouch Size will be 1/3 of the length shown as (a).

  • Page 47: Menu Bar

    Excelon XD/XQ Operator’s Manual 5.2.8 Menu Bar All additional functions are provided in the menu bar for user convenience. Menu bar always displayed on the top of the screen. (1) Job (Job related functions) Job load, Job save, Job delete, internal data, etc.

  • Page 48: Menu Dialog Box

    Excelon XD/XQ Operator’s Manual 5.2.9 Menu Dialog Box All configurations can be set using the Menu Dialog Box. (1) Menu title (2) Sub-menu tab Up to 4 sub-menu entries are displayed in the Sub-menu tab. To select menu just press the tab. Left/Right arrow buttons are used for navigating sub-menus when sub-menu count is more than 4.
  • Page 49 Excelon XD/XQ Operator’s Manual (4) Select/Unselect/Toggle Button (5) Menu item area There are three types of items. Value, List, Check Box.  Value This is an item user can enter value directly. Press the value box and enter the value using the numeric keypad.
  • Page 50 Excelon XD/XQ Operator’s Manual (6) Scroll bar Scroll bar is used for moving around the items. (7) Save/Exit Button Press the save button to apply changes to the system. Or press the exit button to exit without applying the changes.
  • Page 51 Excelon XD/XQ Operator’s Manual If the value entered, information message box displayed on the screen. Select “YES” to apply the value to all.

  • Page 52: Hole Editor Screen(Xd)

    Excelon XD/XQ Operator’s Manual 5.3 Hole Editor Screen(XD) Hole Editor is used for specifying hole position for drilling. Press the Hole Editor button ( ) to enter hole editor screen. 5.3.1 Layout of Hole Editor Hole Position Information Hole Attributes...
  • Page 53 Excelon XD/XQ Operator’s Manual (1) Hole Position Information Horizontal Position Hole Vertical Position Drilling Impossible Area (2) Add Hole (3) Change Hole Type (4) Hole ID / Select Hole (5) Delete Hole (6) Hole Position Reference (Horizontal) (7) Hole Position Reference (Vertical)

  • Page 54: Add Hole

    Excelon XD/XQ Operator’s Manual 5.3.2 Add Hole To add hole, press the “Add” button( ) and then specify hole location in the frame area. To specify hole position accurately, press the hole position value and then enter exact hole position value with numeric keypad.

  • Page 55: Select Hole

    Excelon XD/XQ Operator’s Manual NOTE • Adding a Slot (1) Change hole type to “Slot” (2) Press the start position of the slot in the frame area and then drag. • Slot start point is green, end point is brown.
  • Page 56 Excelon XD/XQ Operator’s Manual NOTE • Use the Hole ID to distinguish hole data. • To specify hole position R/L separately, turn off R/L sync option before specifying position. R/L Sync Off...

  • Page 57: Delete Hole

    Excelon XD/XQ Operator’s Manual 5.3.5 Delete Hole Select hole to delete and then press the delete button( 5.3.6 Hole Position Reference (Horizontal) Center (The distance between the hole and the center of the frame, Temporal : – value, Nasal : + value)

  • Page 58: Hole Position Reference (Vertical)

    Excelon XD/XQ Operator’s Manual 5.3.7 Hole Position Reference (Vertical) Center (Top : + value, Bottom : - value) Top Box Bottom Box NOTE • Vertical Reference Frame Center Bottom NOTE • Hole Position Frame Center (Horizontal) Temporal Box (Horizontal) Frame Center (Vertical)
  • Page 59 Excelon XD/XQ Operator’s Manual Nasal Box (Horizontal) Temporal Frame (Horizontal) Frame Center (Vertical) Frame Center (Vertical) Nasal Frame (Horizontal) Frame Center (Horizontal) Frame Center (Vertical) Top Box (Vertical) Frame Center (Horizontal) Bottom Box (Vertical)

  • Page 60: Undo

    Excelon XD/XQ Operator’s Manual 5.3.8 Undo Press the undo button ( ) to undo the last change. All actions entered by the user are stored automatically, even if hole data deleted by mistake, Hole Editor can easily revert to a previous state.
  • Page 61 Excelon XD/XQ Operator’s Manual NOTE • Undo/Redo Slot diameter 1mm  2mm Undo Slot diameter 1mm Redo Slot diameter 2mm...

  • Page 62: Hole Attributes

    Excelon XD/XQ Operator’s Manual 5.3.10 Hole Attributes Hole attributes (Group, Diameter, Depth, Angle) are displayed on the bottom left of the screen. • Diameter : Hole diameter (Min 0.8 mm) • Depth : Hole depth (0 means through hole) • Angle : Tilting angle (0°~ 30°, Automatic) NOTE •...

  • Page 63: Hole Position Adjustment

    Excelon XD/XQ Operator’s Manual 5.3.11 Hole Position Adjustment This function enables user to adjust hole position easily and accurately. If the adjustment button( ) pressed, additional control panel displayed on the screen. Step Close Press the direction button to change current hole position. (Step value applied) 5.3.12 Exit...

  • Page 64: Group

    Excelon XD/XQ Operator’s Manual 5.3.13 Group Group function enables the possibility of editing multiple holes and slots at the same time. Properties of holes/slots that have the same Group ID can be edited as a group. (1) Making a Group Select a hole and press the Group ID box, then enter the Group ID.
  • Page 65 Excelon XD/XQ Operator’s Manual (2) Change group position If the position of any hole in the group is changed, all group data will be changed simultaneously. This function only works under Group Sync Mode. If the Group Sync Mode disabled, only selected hole data is changed.
  • Page 66 Excelon XD/XQ Operator’s Manual (3) Change group property If the property of any hole in the group is changed, all group data will be changed simultaneously. (Only working under Group Sync Mode) (4) Cancel the group Set to 0 to all Group ID.
  • Page 67 Excelon XD/XQ Operator’s Manual (5) Delete all group data Select a hole or slot data which is in the group, then delete. This removes the entire group element. (This works when Group Sync Mode is activated)

  • Page 68: Hole Data Load/Save

    Excelon XD/XQ Operator’s Manual 5.3.14 Hole data Load/Save All hole data can be saved in the SD memory card for future reuse. (1) Save hole data Select “Job – Hole Data Save” in the menu bar. Enter filename to save. (Max 16 characters) All hole data stored in the SD memory card.
  • Page 69 Excelon XD/XQ Operator’s Manual (2) Load hole data Select “Job – Hole Data Load” in the menu bar to run hole data load dialog box. Select filename to load in the left file list box and then open it. There are three kinds of hole data loading method in the menu.

  • Page 70: Hole Data Preset

    Excelon XD/XQ Operator’s Manual 5.3.15 Hole data preset Hole editor provides 8 built-in hole data for user convenience. To use built-in data, hole data preset feature must be turned on. Check “Use Hole Data Preset” item in the “Option – Configuration – Hole Editor Default”...

  • Page 71: Hole Retouch Mode

    Excelon XD/XQ Operator’s Manual 5.3.16 Hole Retouch Mode If the drilled hole position is not correct, it is possible to readjust hole position in the hole retouch mode. (1) Entering Hole Retouch Mode After drilling, press the Hole Editor icon to enter Hole Editor screen.
  • Page 72 Excelon XD/XQ Operator’s Manual Press the Hole Retouch icon to start Hole Retouch Mode. Hole Retouch Window (2) Select and Adjust Use the selection buttons to select the hole to retouch.
  • Page 73 Excelon XD/XQ Operator’s Manual And then push the Retouch Add button( ) to add the selected hole to Hole Retouch Window. (Retouch Delete button( ) is opposite function of the Retouch Add button) To adjust hole position, press the hole position value displayed on the window and change the value using the numeric keypad.
  • Page 74 Excelon XD/XQ Operator’s Manual the window. (3) Add New Hole It is also possible to add new hole. Press the Hole Add button(...
  • Page 75 Excelon XD/XQ Operator’s Manual See [5.3.2 Add Hole] to setup hole position and property. If the hole position and property are set correctly, press the Retouch Add button to register selected hole to the Hole Retouch window. (4) Start Hole Retouch...
  • Page 76 Excelon XD/XQ Operator’s Manual (5) Exit Hole Retouch Mode Press the exit button to quit the Hole Retouch Mode. If the Hole Retouch Window disappeared, all hole adjustment data are deleted. So caution is needed. (However, newly added hole data in the...
  • Page 77 Excelon XD/XQ Operator’s Manual NOTE • After drilling, all hole editing functions are disabled. (However, if only one side is drilled, the other side can be edited. (R/L sync option is disabled automatically)) • Hole Retouch Mode executed only in the job drilled right before.

  • Page 78: Job Management

    Excelon XD/XQ Operator’s Manual 5.4 Job Management All job data received from auto-blocker or frame reader can be saved to the SD memory card for future reuse. 5.4.1 Job Save Select “Job – Job Save” in the menu bar to save job data.
  • Page 79 Excelon XD/XQ Operator’s Manual NOTE • To avoid filename duplication change job number before saving. • Press the job tab again to change current job number. (Job number can be up to 16 characters)

  • Page 80: Job Load

    Excelon XD/XQ Operator’s Manual 5.4.2 Job Load Select “Job – Job Load” in the menu bar to run job load dialog box. All job data in the SD memory card listed in the dialog box. If the job file selected in the left file list box, job data displayed in the right preview window.
  • Page 81 Excelon XD/XQ Operator’s Manual NOTE • To delete job data in the SD memory card, press the “Delete” button.

  • Page 82: Internal Data

    Excelon XD/XQ Operator’s Manual 5.4.3 Internal Data 6 internal job data (Rectangle, Ellipse, Frame, Circle, Pentagon, Standard Pattern) are built in the program. This job data is used for testing edging quality. To use internal data, select the data from the “Job”...
  • Page 83 Excelon XD/XQ Operator’s Manual To unregister frame change lens, select “Job – Frame Change Lens” again in the menu bar. NOTE • How to frame change (1) Tracing old lens in the frame reader. (the lens blocked at optical center) (2) Register the job received from frame reader to frame change lens.
  • Page 84 Excelon XD/XQ Operator’s Manual • The new lens must located in the old lens to start edging process. If interference occurs, error message is displayed and edging process stopped. • The above procedure only applies only in frame reader and manual blocker configuration.

  • Page 85: User Defined Options

    Excelon XD/XQ Operator’s Manual 6. User Defined Options 6.1 Configuration • Menu Bar  Option  Configuration Configuration menu lets user customize many aspects of the way edger program works. 6.1.1 General • language Select the language. • Sleep Mode Specify Sleep mode time.

  • Page 86: Layout Default

    Excelon XD/XQ Operator’s Manual • Realtime Edging Window (expr) Realtime Edging Window – Show edging progress window when edging started. Progress Bar Only – Show only edging steps • Disable processed job editing Processed job cannot be modified. • Show Blocking Offset Shows manual blocker guide line on the frame area (Boxing center.only)

  • Page 87: Edging Default

    Excelon XD/XQ Operator’s Manual Select R/L Sync Mode • Safety Check Setup parameters for safety check function. Safety Check Margin – Margin value for lens adaptor Frame Change Margin – Margin value for frame change lens Use Small Lens Adaptor – Show warning message when small lens adaptor needed 6.1.3 Edging Default...

  • Page 88: Hole Editor Default (Xd)

    Excelon XD/XQ Operator’s Manual 6.1.4 Hole Editor Default (XD) • X Pos Reference/ Y Pos Reference Select default hole position coordinates reference X (Horizontal) – frame center / temporal box / nasal box Y (Vertical) – frame center / Top box / Bottom Box •...
  • Page 89 Excelon XD/XQ Operator’s Manual NOTE • Automatic correction of hole position If the curvature of lens is different from that of demo lens, the distance of hole from lens edge can be longer or shorter than desired. Automatic correction of hole position is a function which compensate drilling hole position automatically by comparing curvatures of demo lens and actual lens.
  • Page 90 Excelon XD/XQ Operator’s Manual If, Demo lens’s curvature > Real lens’s curvature value applied to drilling hole position • How to use Automatic correction of hole position Function...

  • Page 91: Frame Fitting

    Excelon XD/XQ Operator’s Manual If the “Use Demo Lens Curve” option is turned on, the following dialog box is displayed on the screen when drilling started. Select “Yes” to apply default demo lens curve value specified in the menu or Select “No”...
  • Page 92 Excelon XD/XQ Operator’s Manual • How to setup frame fitting values (1) Trace the frame with Frame Reader (2) Execute the edging process with Mid-Index Lens (low diopter lens preferred) and carry out the fitting with the edged lens. (3) In case the edged lens is bigger than the frame, adjust the value to ‘-‘ (minus).

  • Page 93: Adjustment

    CAUTION • Adjustment values are closely related to the processing quality, so keep the fact ory default values. • Before changing these values, ask advice of the service technician of Huvitz or the technician authorized by Huvitz. 6.3.1 Size Adjustment Size Adjustment values are closely related to the size of the edged lens.

  • Page 94: Margin Adjustment

    Excelon XD/XQ Operator’s Manual NOTE • How to input adjustment value (Plastic, flat edging without polishing) Edged lens 52mm Circle (Ø 50) Enter -1 in the “Finishing  Rimless  PL” item. 6.3.2 Margin Adjustment Setup margin values for next edging step.

  • Page 95: Axis Adjustment

    Excelon XD/XQ Operator’s Manual 6.3.3 Axis Adjustment These values are used for compensating distortion of axis during the edging process. • Test Pattern - Draw a horizontal line on the lens and put the lens adaptor. [After blocking the test lens] - Execute the internal Square(40mm X 40mm) •...

  • Page 96: Bevel Adjustment

    Excelon XD/XQ Operator’s Manual b. Safety beveling axis adjustment Front Front Rear Add (-) value Add (+) value Add (+) value c. Grooving axis adjustment Add (-) value Add (+) value d. Polishing axis adjustment Add (-) value Add (+) value 6.3.4 Bevel Adjustment...
  • Page 97 Excelon XD/XQ Operator’s Manual NOTE • Follow the next instructions to adjust the incorrect beveling. a. The movement of beveled position Bevel Position – Lens – Position Rear Front b. The effect of adding (-) value for the beveled position c.

  • Page 98: Grooving Adjustment

    Excelon XD/XQ Operator’s Manual 6.3.5 Grooving Adjustment These values are used for adjusting groove position. • Test Pattern - Execute the Circle pattern (Ø 50) with the grooving position 50%. • Test Cases - Check the grooving position and depth.

  • Page 99: Safety Beveling Adjustment

    Excelon XD/XQ Operator’s Manual 6.3.6 Safety Beveling Adjustment These values are used for adjusting safety bevel position. • Test Pattern - Execute the Circle pattern (Ø 50) with/without bevel (position 50%) • Test Cases - Execute above two kinds of processes for each of materials including plastic, PC, HI-Index lens and Trivex®...

  • Page 100: Clamp Pressure

    Excelon XD/XQ Operator’s Manual After adding(+) in SFB Front side 6.3.7 Clamp Pressure Setup default clamping pressure for each lens material. 6.3.8 Processing Speed • Rotation Limit Set amount of lens rotation for each edging step. • Rotation Speed Set lens rotation speed for each edging step and each material.

  • Page 101: System Adjustment

    Excelon XD/XQ Operator’s Manual 6.3.9 System Adjustment • Polish Wheel Size Enter compensation value for polishing wheel size. • Max Rimless Thickness Set maximum lens thickness for rimless edging. (This value should match the width of the wheel) • Wheel for HI Select the roughing edging wheel for HI-Index lens.

  • Page 102: Drilling Adjustment

    Excelon XD/XQ Operator’s Manual 6.3.10 Drilling Adjustment These values are used for adjusting drilling quality. • Select Drill Bit Select drill bit size (Ø 0.8mm or 1.0mm) • Drill Feeding Method Select default drill feeding method (Once, Repeat) For accurate drilling, the edger must meet the following conditions.
  • Page 103 Excelon XD/XQ Operator’s Manual Check the drill hole diameter with ⑥. (Drill Hole Diameter Adjustment) Check the hole size whether the Ø 2.0mm straight pin passes through the hole softly. Check the drill axis with ⑦and ⑧. (Drill Angle Adjustment) Two holes are parallel with the lens edge.
  • Page 104 Excelon XD/XQ Operator’s Manual If the result doesn’t meet the condition, perform the specified adjustment procedure. 6.3.10.1 Drill Depth Adjustment. Load “Drill Depth Adj” data in the Job menu and then start processing. Diameter Depth Tilting (mm) (mm) ① ①...
  • Page 105 Excelon XD/XQ Operator’s Manual 6.3.10.2 Drill Hole Diameter Adjustment Load “Drill Hole Dia Adj” data in the Job menu and then start processing. Diameter Tilting (°) (mm) ① ① 1.90 Auto ② ② 1.95 Auto ③ ③ 2.00 Auto ④...
  • Page 106 Excelon XD/XQ Operator’s Manual 6.3.10.3 Drill Angle & Position Adjustment Load “Drill Angle & Pos Adj” data in the Job menu and then start processing. ③ ② ① Diameter Tilting Type (mm) (°) ① Hole ② Hole ③ Slot ④...
  • Page 107 Excelon XD/XQ Operator’s Manual 6.3.10.4 Drill Tip Axis Adjustment Load “Drill Tip Angle Adj” data in the Job menu and then start processing. ①,② Diameter Tilting (mm) (°) ③,④ ①,③,⑤,⑦,⑨ ⑤,⑥ ②,④,⑥,⑧⑩ 30.0 ⑦,⑧ ⑨,⑩ Drill Tip Angle Adjustment Pattern If the overlapped hole found, adjust “Drill Tip Angle Adj”...

  • Page 108: Configuration Management

    • Restore configuration data from SD card Clear current configuration data and restore backuped configuration data from SD memory card. • FRAM Init Initialize internal memory structure. (ask advice of the service technician of Huvitz or the technician authorized by Huvitz)

  • Page 109: System Maintenance

    Excelon XD/XQ Operator’s Manual 7. System Maintenance 7.1 Setup Time • Menu Bar  Tool  Setup Time This is the menu for changing system time. Make sure to reset system time after installation. 7.2 Test Mode • Menu Bar  Tool  Test Mode Test Mode helps user to find out whether the machine working properly or not.
  • Page 110 Excelon XD/XQ Operator’s Manual R – R axis PI sensor value Contact – Main contact switch status (2) Feeler & Wheel Left – (Left feeler switch status) Left feeler encoder value Right – (right feeler switch status) Right feeler encoder value Motor –...
  • Page 111 Excelon XD/XQ Operator’s Manual Pump1 – Pump 1 status Pump2 – Pump 2 status (4) SBG & Clamp SBG – Safety Beveling & Grooving module PI sensor value Contact - Safety Beveling & Grooving module contact switch status Motor - Safety Beveling & Grooving motor status Current - Safety Beveling &...

  • Page 112: Wheel Dressing

    Excelon XD/XQ Operator’s Manual T – Drill module tilting PI sensor value Motor – Drilling motor status Current – Drilling motor current value 7.3 Wheel Dressing • Menu Bar  Tool  Wheel Dressing Wheel Dressing is useful to maintain the wheel performance by way of removing the lens debris stick to the wheel.
  • Page 113 Excelon XD/XQ Operator’s Manual...

  • Page 114: Automatic Calibration

    Excelon XD/XQ Operator’s Manual 7.5 Automatic Calibration • Menu Bar  Tool  Calibration Four kinds of calibration can be done with standard edging jig. Those are Size Calibration, Feeler Calibration, Grooving Calibration and Safety Beveling Calibration. How to calibrate edger (1) Place standard edging JIG instead of lens adaptor holder.
  • Page 115 Excelon XD/XQ Operator’s Manual NOTE • To reset current statistics value press the value area in the dialog box. • Wheel statistics values are used for warning wheel replacement. These values are not related to wheel life time. • To reset wheel statistics value press the wheel label area in the dialog box.

  • Page 116: Maintenance Tips

    It is recommended to keep the regular maintenance cycle in order to maintain the Edging Performance. Be sure to carry out the regular maintenance by the service technician of Huvitz or the technician authorized by Huvitz. • Regular Maintenance Cycle : 1,500 ~ 2,000 pieces of Lens edged ▪...

  • Page 117: Standard Accessory

    Excelon XD/XQ Operator’s Manual Standard Accessory Operator’s Manual ············································································ 1 Lens Adapter (Circle) ········································································ 15 Lens Clamp Rubber (Circle) ··································································5 LEAP-III Tape (500 Pads) ······································································1 Lens Adapter Remover ·········································································1 Standard Frame (for Frame Reader Calibration) ············································1 Standard Pattern (for Frame Reader Calibration) ·············································1 Pattern Holder ·····················································································1...

  • Page 118: Specification

    Excelon XD/XQ Operator’s Manual Specification Edger Edging System Auto Edging Mode Beveling Flat Edging Grooving Safety Beveling Polishing Drilling (XD) Lens Material Plastic, Glass, Polycarbonate, Hi-lndex, Trivex® Edging Size Maximum 90mm Minimum 18mm Weight 55 kg Power Supply AC 110/220V, 50/60Hz...

  • Page 119: Drawings Of System

    Excelon XD/XQ Operator’s Manual Drawings of System...
  • Page 120 Excelon XD/XQ Operator’s Manual...
