Reset control

5 Reset control
5.1

Reset management overview

The reset cell is a dedicated 5 V bidirectional I/O. Its output buffer driving capability is fixed
to Io = 2 mA at 0.4 V in the 3 V to 5.5 V range, which includes a 40 kΩ pull-up. Output
MIN
buffer is reduced to the n-channel MOSFET (NMOS). If a 40 kΩ pull-up is accepted, this cell
does not include an output buffer of 5 V capability. The receiver includes a glitch filter,
whereas the output buffer includes a 20 µs delay.
There are many reset sources, including:
• External reset through the NRST pin
•
Power-on reset (POR) and brown-out reset (BOR): during power-on, the POR keeps
the device under reset until the supply voltage (V
at which the BOR starts to function.
•
Independent watchdog reset (IWDG)
•
Window watchdog reset (WWDG)
•
Software reset: the application software can trigger reset
•
SWIM reset: an external device connected to the SWIM interface can request the
SWIM block to generate a microcontroller reset
•
Illegal opcode reset: if a code to be executed does not correspond to any opcode or
prebyte value, a reset is generated
•
Electromagnetic susceptibility (EMS) reset: generated if critical registers are corrupted
or badly loaded
14/40

Figure 7. Reset management

STM8
VDD_IO
R
NRST
AN2752 Rev 6
DD
PU
Filter
Pulse generator
(min 20 µs
Delay
and V ) reach the voltage level
DDIO
Simplified functional I/O reset schematic
System reset
Illegal op code reset
IWDG/WWDG/software reset
SWIM reset
EMS reset
POR/BOR reset
