RT530E-2 SERVICE MANUAL
Item
1 Front Outrigger Control Manifold
2 Outrigger/Rear Steer Valve
3 Differential Lock Valve
4 Park Brake Range Shift Valve
GROVE
1
5
7
2
CARRIER
Description
Published 4-22-15, Control # 556-00
3
4
6725
Item Description
5 Axle Lockout Valve
6 Rear Outrigger Control manifold
7 Frame
HYDRAULIC SYSTEM
6
FIGURE 2-14 continued
2-29
