RT530E-2 SERVICE MANUAL
1
1
2
3
8481
Item
1 Cotter Pin
2 Pin
3 Pin
4 Lockout Cylinder
5 Steer Cylinder
6
7 Pin Weld
8 Pin Weld
9 Capscrew
10 Lockwasher
11 Flatwasher
GROVE
15
8
4
Description
Published 4-22-15, Control # 556-00
14
16
7
17
21
22
6
11
10
9
Item
12 Capscrew
13 Washer
14 Hex Nut
15 Capscrew
16 Lockwasher
17 Flatwasher
18 Sensor Plate
19 Capscrew
20 Lockwasher
21 Rear Axle
22 Grease Fitting
23 Flatwasher
UNDERCARRIAGE
19
20
18
13
23
12
5
FIGURE 8-1
Description
8
8-3
