ELECTRIC SYSTEM
3-28
Fault Code
6429 Counterweight Raise solenoid
6430 Counterweight Unlock solenoid
6431 Counterweight Lock solenoid
6432 Aux hoist carrier raise
6433 Aux hoist carrier lower
6434 Aux hoist lock
6435 Aux hoist unlock
6436 Main hoist Fast Moving
6437 Aux hoist Fast Moving
6438 Pressure Limiter Valve
6600 Main Hoist Speed Control PWM output
6601 Aux Hoist Speed Control PWM output
6602 Derricking Speed Control PWM output
6603 Telescoping Speed Control PWM output
6604 Slewing Speed Control PMW output
6605 Boom Down Release PWM output
6606 Tele Pressure Extend PWM output
6607 Slew Brake PWM output
6608 Aux Drives Speed Control PWM output
6609 Oil Cooler 1A PWM output
6610 Oil Cooler 1B PWM output
6611 Oil Cooler 2A PWM output
6612 Oil Cooler 2B PWM output
6614 Oil heater cooler
7001 Hydac Pressure Sensor (default node ID)
7002 SCM0
7003 SCM1
7004 SCM2
7005 SCM3
7013 Pressure sensor lower chamber 0
7014 Pressure sensor lower chamber 1
7015 Pressure sensor upper chamber
7017 Length sensor BOOM length
7018 Length sensor telecylinder length
7019 Telescoping Cylinder CAN length sensor
7020 Boom angle sensor 0
7021 Boom angle sensor 1
7022 Jib angle sensor
Published 4-22-15, Control # 556-00
Component Description
RT530E-2 SERVICE MANUAL
