RT530E-2 SERVICE MANUAL
GROVE
Item Description
1 Counterweight
2 Pin Assembly
3 Capscrew
4 Hex Nut
5 Jam Nut
6 Grill
7 Retaining Nut
8 Flat Washer
9 Lock Washer
10 Capscrew
11 Lock Pin
Published 4-22-15, Control # 556-00
HOIST AND COUNTERWEIGHT
3, 4, 5
2, 11
3, 4, 5
2, 11
7, 8, 9, 10
6
1
6830
FIGURE 5-7
5-15
5
