Manitowoc Grove RT530E-2 Service And Maintenance Manual page 100

HYDRAULIC SYSTEM
13
14
20
2
Item
1 Barrel
2 Rod Assembly
3 Head
4 Lip Seal
5 Wear Ring
6 O-ring
7 Backup Ring
8 Wear Ring
9 Buffer Ring
10 Lip Seal
2-66
18
17
8
9
10
11
Description
Published 4-22-15, Control # 556-00
19
17
1
15
6
16
3
Item
11 Wiper Ring
12 Retainer Ring
13 Bleeder Plug
14 Grease Fitting
15 Grease Fitting
16 Screw
17 O-ring
18 Plug
19 Plug
20 Check Valve
RT530E-2 SERVICE MANUAL
5
4
5
7
12
6732
FIGURE 2-37
Description
