RT530E-2 SERVICE MANUAL
Table 3-6Amp Extraction Tool Table
Description
14 gauge wire (connectors)
12 to 8 gauge wire (connectors)
4 to 9 circuit (in-line connectors)
15 circuit (in-line connectors)
Table 3-7
Amp Crimping Tool Table
Description
14 to 12 gauge wire
10 to 8 gauge wire
4 to 9 circuit
(in-line connectors
15 circuit
(in-line connectors
Table 3-8
Deutsch Extraction Tool Table
Description
12 gauge wire
16 gauge wire
8-10 gauge wire
4-6 gauge wire
Table 3-9
Deutsch Crimping Tool Table
Description
12, 14, 16, 18, 20 gauge wire
4, 6, 8, 10 gauge wire
GROVE
Amp Part Number
305183
91019-3
453300-1
458944-1
Amp Part Number
Tool Die
69710-1 90145-1
69710-1 90140-1
69710-1 90306-1
90299-1 --
Deutsch Part Number
114010
0411-204-1605
114008
114009
Deutsch Part Number
HDT48-00
HDT 04-08
Published 4-22-15, Control # 556-00
ELECTRIC SYSTEM
Grove Part Number
9999100176
9999100175
N/A
N/A
Grove Part Number
Tool
9999100177
9999100177 9999100178
9999100177
N/A
Grove Part Number
9999100194
9999100195
7902000012
7902000009
Grove Part Number
9999100808
9999100842
3
Die
N/A
N/A
--
3-15
