RT530E-2 SERVICE MANUAL
:
Table 3-2 Superstructure Cab Fuse Box
Fuse Protects
F1 Keyswitch Ignition Relay
F2 Open
F3 Ignition On Signal
Keyswitch Ignition On
D1
Signal
Brake Pedal Press
D2
Switch Signal
Hazard Lights On
D3
Switch Signal
Marker Lights On Switch
D4
Signal
D5 Horn On Signal
Table 3-3: Carrier Fuses and Relays
Fuse Protects
Superstructure Module
F1
PCB Power
F2 CraneStar Power
F3 Diagnostic Tool Power
Carrier Module Battery
F4
Power
Carrier Module Battery
F5
Power
F6 Engine ECM Power
F7 Relay Power
F8 Reverse Power
Carrier Module PCB
F9
Power
KC1 Headlight Relay
KC2 Starter Lockout Relay
KC3 Reverse Relay
KC4 Ignition On Relay
GROVE
Table 3-4
Amps Location
3 (Figure 3-3)
(Figure 3-3)
3 (Figure 3-3)
(Figure 3-3)
(Figure 3-3)
(Figure 3-3)

Relays

(Figure 3-3)
The relays are located at the back of the battery box
(Figure 3-4): Includes K-301 start relay (1) and K-302 grid
(Figure 3-3)
heater relay (2).
Amps Location
20 (Figure 3-4)
5 (Figure 3-4)
5 (Figure 3-4)
15 (Figure 3-4)
15 (Figure 3-4)
30 (Figure 3-4)
10 (Figure 3-4)
15 (Figure 3-4)
15 (Figure 3-4)
(Figure 3-4)
8090-4A
(Figure 3-4)
(Figure 3-4)
(Figure 3-4)
Published 4-22-15, Control # 556-00
:
Carrier Fuses and Relays
Fuse Protects
F51 Alternator
F52 Swivel
F53 Swivel
F54 Swivel
F55 Main Power
F56 Grid Heater Power
1
2
4
ELECTRIC SYSTEM
Amps Location
100 (Figure 3-4)
100 (Figure 3-4)
100 (Figure 3-4)
100 (Figure 3-4)
125 (Figure 3-4)
100 (Figure 3-4)
4
3
FIGURE 3-4
3-3
3
