BOOM
Item
1 Fly Section
2 Outer Mid Section
3 Inner Mid Section
4 Base Section
5 Telescope Cylinder Barrel
6 Sheave Mounting Assembly
7 Extend Cable Sheave Assembly
8 Extend Sheave Shaft
9 Cable Retainer
10 Fly Extend Cables
11 Support Foot Weldment
12 Wear Pads
13 Cable Retainer Pin
14 End Cap
4-4
Description
Published 4-22-15, Control # 556-00
RT530E-2 SERVICE MANUAL
Item
15 Upper Boom Nose Sheaves
16 Lower Boom Nose Sheaves
17 Kicker Plate
18 Front Top and Bottom Side Wear Pads
19 Bottom Front Wear Pads
20 Grease Fittings
21 Extend Synchronizing Cable
22 Fly Retract Cables
23 Outer Mid Retract Cables
24 Kicker Plates
25 Extend Synchronizing Cable Sheave Assembles
26 A2B Roller Guide Mounting Angle
27 Retract Cable Anchor Plates
Description
