Manitowoc Grove RT530E-2 Service And Maintenance Manual page 179

RT530E-2 SERVICE MANUAL
13
12
11
Item
1 Boom Base Section
2 Inner Mid Section
3 Outer Mid Section
4 Fly Section
5 Upper Sheave Cable Retainer
6 Left SIde Attachment Pins
7 Boom Nose Dead End Lug
8 Lower Sheave Cable Retainer
GROVE
5
4
14
15
10
8
9
Description
Published 4-22-15, Control # 556-00
2
3
6
7
6033
Item
9 Alignment Jack
10 Offset Pin
11 Mast Assembly Stowage Pin
12 Mast Assembly
13 Mast Assembly Cable Retainer
14 Right Side Attachment Pins
15 Jack handle
BOOM
1
FIGURE 4-37
Description
4
4-31
