HYDRAULIC SYSTEM
6
8
7
8
Item
1 Barrel
2 Rod
3 Piston
4 Head
5 Spacer
6 Nut
7 Piston Seal
8. Install the replacement piston seal and wear rings on the
2-72
3
2
9
14
12
10
Description
Published 4-22-15, Control # 556-00
1
13
11
Item
8 Wear Ring
9 O-ring
10 O-ring
11 Backup Ring
12 Seal
13 Wiper
14 Wear Ring
outside of the piston.
RT530E-2 SERVICE MANUAL
2
5
4
6815
FIGURE 2-39
Description
