ELECTRIC SYSTEM
3-34
Fault Code
35 The internal supply voltage UC2 is too low
36 Analog Input error
37 Digital Input error
38 Digital Output error
39 PWM Output error
40 Task Time too long
41 Data is not valid
42 Device is not operational
43 Could not get semaphore
44 Data does not match required data
The counter from a connected CAN device is no longer
45
being updated. The data is considered no longer valid.
46 A CAN device is reporting a self-detected error
The pinning system could not unlock within the required
47
time limit
48 The current operating mode is invalid
49 Movement in opposite direction
50 Unintentional Lock
52 The internal supply voltage UF is too low
53 The internal supply voltage UE is too low
54 The internal supply voltage UF is out of range
55 The internal supply voltage UB1 is out of range
56 The internal supply voltage UB2 is out of range
57 The internal supply voltage UC1 is out of range
58 The internal supply voltage UC2 is out of range
59 The external supply voltage EXT is out of range
60 Outrigger base too small
61 Jib angle tolerance
The last reset was because the watchdog detected that
128
Ue was above the maximum allowed value
The last reset was because the watchdog detected that
129
Ue was below the minimum allowed value
The last reset was because the watchdog detected that
130 the system voltage was above the maximum allowed
value
The last reset was because the watchdog detected that
131
the system voltage was below the minimum allowed value
The last reset was because the watchdog detected an
132
error as defined by the user
The last reset was because the watchdog detected a
133
system error
Published 4-22-15, Control # 556-00
Condition Description
