2.5 Types of UPS Cabinet

There are two series of UPS cabinets, standard and extended for different requirements.
The standard cabinets have the battery modules inside and they can work as a stand-alone UPS or
be connected to battery externally.
The extended cabinets don't have the battery module compartments. The battery has to be
connected externally.
Please consider the external battery space and wiring gauge for installation.
Mod5T
90/30
Cabinet
30U
Height
Switch
1
Unit
STS 1
Max.
Power 3
Module
Battery
12
Module
*Max power 210 kVA / Configuration 7+1
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 04 17 AA 59 201 06
Mod5T Mod5T
120/30 120/30 S
42U 30U
1 1
1 1
4 4
20 N/A
Mod5T Mod5T
180/30 S 210/30 S
30U 42U
1 1
1 1
6 8*
N/A N/A
Mod5T
300/30 S
42U
1
1
10
N/A
