Step 5
It is possible to change the STS
module, Power Module and Battery
Module.
3.3.3.2 Transfer to UPS Protection
90KVA~210KVA.
Step 1
Make sure the maintenance is
complete. The Power Modules and STS
module have been installed well.
Step 2
Switch ON the Main Breaker (Q1) and
Output breaker (Q3) as shown below.
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 04 17 AA 59 201 06
300KVA
Make sure the maintenance is
complete. The Power Modules and STS
module have been installed well.
Please enter LCD SETUP MENU and
choose "SYSTEM" to ensure that the
"Bypass mode" is enabled. If the
"Bypass mode" is disabled, you have to
set it enabled. Then, exit the SETUP
menu and check if the UPS operates in
bypass mode.
49
