INFOSEC UPS SYSTEM ModT User Manual page 82

27 Setup! Save Setting
29 Setup! Power Rating Setting
31 Setup! Nominal Battery Voltage
33 Setup! Maximum Charging Current
35 Setup! Battery Low Capacity
37 Setup! Periodic Battery Test
39 Setup! BATTERY Age Alert
41 Setup! Charging Voltage
43 Setup! UPS Parallel
45 Setup! Auto-restart battery voltage
Table 4-14: UPS mode change
Item
No.
1 UPS Mode! Power On Mode
3 UPS Mode! Bypass Mode
5 UPS Mode! Battery Mode
7 UPS Mode! Fault Mode
9 UPS Mode! ECO Mode
11 UPS Mode! Un-Connection
Table 4-15: Control execution
Item
No.
1 Control! System Turn On
3 Control! Manual Battery Test
5 Control! Turn To Bypass
7 Control! Cancel Shutdown
9 Control! Charger Turn Off
