INFOSEC UPS SYSTEM ModT User Manual page 80

Fault! Inverter Voltage Over
Fault! Inverter Voltage High
Fault! Inverter Voltage Low
Fault! R Inverter Voltage Short
Fault! S Inverter Voltage Short
Fault! T Inverter Voltage Short
Fault! RS Inverter Voltage Short
Fault! ST Inverter Voltage Short
Fault! TR Inverter Voltage Short
Fault! Inverter R Negative Power
Fault! Inverter S Negative Power
Fault! Inverter T Negative Power
Fault! Over Load Fault
Fault! Battery Fault
Fault! Over Temperature
Fault! CAN Fault
Fault! TRIG0 Fault
Fault! Relay Fault
Fault! Line SCR Fail
Fault! EEPROM Fault
Fault! Parallel Cable Loosen Fault
Fault! DSP MCU Stop Communicate
Fault! Bypass Temperature Fault
Fault! Bypass SCR Fault
Line Fail
Line Restore
Warning! EPO Active
Warning! Over Load Fail
Warning! Communicate CAN Fail
Warning! Over Load
Warning! Battery Open
Warning! Battery voltage High
Warning! Module Un-Lock
Warning! Turn On Abnormal
Warning! Charge Fail
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 04 17 AA 59 201 06
Inverter Voltage is over Peak Value.
Inverter Voltage is too high
Inverter Voltage is too Low
R phase inverter Output is short-circuited.
S phase inverter Output is short-circuited.
T phase inverter Output is short-circuited.
R-S inverter Output is short-circuited.
S-T inverter Output is short-circuited.
T-R inverter Output is short-circuited.
R phase inverter Output Negative Power over range
S phase inverter Output Negative Power over range
T phase inverter Output Negative Power over range
Heavy overload causes UPS fault.
Batteries reversed
Make sure adequate space is allowed for air ventilation
and the fan is working
CAN communication fault
Synchronized trigger signal fault
Inverter relay fault
Line SCR short circuit fault
EEPROM operation error
As stated.
As stated.
As stated
As stated.
Utility lost or abnormal
Utility recovered to normal
Check the EPO connector
The load devices are demanding more power than the
UPS can supply. Line mode will transfer to Bypass
mode.
CAN communication error
In Line mode, the load devices are demanding more
power than the UPS can supply.
Battery not connected
Battery voltage is too High
As stated.
As stated.
As stated.
