10.4

System Status Monitor

The system status monitor, which is always displayed, provides date, time, equipment
status and navigation data.
File Edit
Date
Time
Position
Waypoint
Course
Speed
Current NCS
Current Channel
Current TDM
MES Status
GPS Status
DCE Memory
Current State: IDLE
DCE F18 Ver. xx
xx: Program Version No. of TERMCPU Board
How to read the system status monitor
Date: Current date.
Time: Current time.
Position: Own ship L/L position (either manual entry or automatic input by navigator).
Waypoint: L/L position of destination waypoint set on navigator.
Course: Course.
Speed: Ship's speed.
Current NCS: NCS your vessel is logged in with.
Current Channel: Channel in use.
Current TDM: Channel TDM.
MES Status: Operational status of MES.
GPS Status: Receiving signal status from GPS receiver.
CST: Cold Start.
ACQ: Acquired; Almanac data acquired.
IMP: Impossible; cannot receive GPS signal.
INT: Interrupted; object interfering with reception of GPS signal.
ALM: Receiving the almanac.
2D, 3D: Position-fixing method by 2D or 3D.
DCE Memory: Memory remaining in communication unit.
BBER: Bulletin Board Error Rate (%).
C/N: Check of circuit status with LES, receiving circuit in antenna unit and TERMCPU
Board in terminal unit. OK appears for figure greater than 31.
Send Level: TX level check. At transmission, OK appears for figure greater than 100.
At reception, 0 always appears.
Rx AGC Level: Check of the receiving circuit of the antenna unit and the TERMCPU
Board in the terminal unit. OK appears for figure greater than 60.
Transmit EGC Reports Logs
Jan-12-12
01:32 (UTC)
LAT 34:30.00N
LON 135:00.00E
LAT
LON
345.5 DEG
10.2 kn
344 (IOR/EMEA) LOGOUT
NCS CC
NCS CC
Idle
****
32818 Bytes free
Retuning
NCS: IOR/EMEA LOGOUT
REC. MESSAGE EXIST
10. MAINTENANCE AND TROUBLESHOOTING
Options Setup Distress StopAlarm
IMN: 443156710
BBER 000
C/N OK (
Send Level OK (
Rx AGC Level OK (254)
REF Offset Freq OK (
Synthe Local OK
TCXO Control 131
Antenna Power Supply OK(7.4V)
Water Temperature
68.2 DEG
Water Current
Direction
232 DEG
Speed 1.9 kn
Depth
Jan-12-12 01:32 (UTC)
LAT: 34:30.00N
LON: 135:00.00E
0 dB)
0)
0 Hz)
10-5
