Wiring - Rosslare AC-G4 Series Installation And Programming Manual

Installation
7. Screw the back plate into the surface. Ensure the screws are the
size specified on the installation template.
The unit can also be mounted using strong epoxy glue. After
application, firmly hold the unit in place until the glue dries.
8. Carefully re-attach the front cover of the unit.
9. Secure the front cover by using the supplied security Torx screw.
A Torx security screw tool is provided to tighten the security Torx
screw.
3.2

Wiring

The unit is supplied with a 10-conductor 100-cm (40-in.) pigtail
(18-AWG cable) with exposed wires coated with solder.
To wire the controller:
1. Select the appropriate connections according to Table 1.
2. Prepare the secured power supply's cable by cutting the cable
jacket back 3.2 cm (1¼") and strip the wire 1.3 cm (½").
AC-F/G4x Series Installation and Programming Manual
Table 1: Wiring Color Guide
Color Description
Red V input
Black Ground
Green REX/BL
White In / Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.
13
