Installation
3. Insert the wall plugs into both mounting holes.
4. Drill a 10-mm (7/16") hole for the cable. If the surface is metal,
place a grommet or electrical tape around the edge of the hole.
5. Insert the unit's cable wire into the cable hole and wire the unit
as described in Section 3.2.
6. Using the two mounting screws, screw the unit to the wall
through the two wall plugs.
The unit can also be mounted using strong epoxy glue. After
application, firmly hold the unit in place until the glue dries.
3.2

Wiring

The unit is supplied with a 6-conductor 150-cm (60-in.) pigtail with
exposed wires coated with solder.
3.2.1

Wiring the Unit as a Reader

If you connect the unit to a standard access control unit, it
automatically functions as a reader.
To connect the unit as a reader (to a controller):
1. Select the appropriate connections according to Table 1.

Table 1: Wiring the Reader to the Controller

2. Prepare the controller cable by cutting the cable jacket back 3.2
cm (1¼") and strip the wire 1.3 cm (½").
3. Splice the reader's pigtail wires to the corresponding controller
wires and cover each joint with insulating tape.
14 AYC-Ex5/T65 Series Installation and Programming Manual
Wire Color Function
Black/Shield
Red
Green
White
Brown
Purple
Ground (+)
Vin (-)
Data 0/Data (D0)
Data 1/Clock (D1)
LED control
Tamper
