Installation
3.2

Wiring

The unit is supplied with a 10-conductor 100-cm (40-in.) pigtail
(18-AWG cable) with exposed wires coated with solder.
To wire the controller:
1. Select the appropriate connections according to Table 1.
2. Prepare the secured power supply's cable by cutting the
cable jacket back 3.2 cm (1¼") and strip the wire 1.3 cm
(½").
18 AC-F/G4x Series Installation and Programming Manual
Table 1: Wiring Color Guide
Color Description
Red V input
Black Ground
Green REX/BL
White In / Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.
