Technical Specifications

2. Technical Specifications
Input VDC
Voltage
VAC
Maximum Input Current
(12 VDC)
Standby Input Current
(12 VDC)
Maximum Relay Current
REX Input
Aux. Input
Max. Proximity Read
Range*
Proximity Modulation
Proximity Card
Compatibility
LED Indicators
Operating Temp. Range
Operating Humidity
Range
Outdoor Usage
Size (H x W x D)
Weight
* Measured using a Rosslare proximity card or equivalent. Range also depends
on electrical environment and proximity to metal.
AC-F/G4x Series Installation and Programming Manual
AC-F43 AC-F44
125 mA 160 mA
75 mA 95 mA
Normally Open (dry contact)
Normally Open (dry contact)
N/A 75 mm
(3.0 in.)
N/A ASK at 125
N/A 26 Bits EM
cards
Two 3-colored LED (Mode and Door)
-30°C to 65°C (-22°F to 150°F)
0 to 95% (non-condensing)
Weather resistant, meets IP65, epoxy-potted
120.9 x 71.1 x 29.7 mm
(4.7 x 2.8 x 1.2 in.)
244 g (8.6 oz)
AC-G43 AC-G44
12 to 24 VDC
16 to 24 VAC
125 mA
75 mA
2 A
N/A
N/A
kHz
N/A
135.4 x 44.2 x 28.5 mm
(5.3 x 1.7 x 1.1 in.)
178 g (6.3 oz)
160 mA
95 mA
80 mm
(3.2 in.)
ASK at 125
kHz
26 Bits EM
cards
