Quick Guide
Turnkey Kit – Initial Connection
Introduction
Thank you for buying the Rosslare turnkey kit. This quick guide will assist you though your initial
connection. For more detailed instructions, please refer to each component's manual, which can be
found on our website.
Kit Contents
Access control panel
2 readers, 25 credentials (AC-225IP)
4 readers, 50 credentials (AC-825IP)
Mini-PC
Mini-PC Accessories
HDMI to VGA adapter
HDMI to HDMI cable
Power supply for Mini-PC
Mounting Accessories for Access Control Panels
Mounting screws
Wall anchors
Metal enclosure keys
EOL resistor kit (2.2K and 8.2K)
Terminal block extraction tool
Power cable
Power lock kit
Mounting Accessories for Readers
Mounting screws (M3 x 25)
Wall anchors
Pin Torx security screws
Pin Torx key tool
Mounting template labels
AC-225IP
3 (M3.5 x 32)
5 (#10 x 1-1/4")
3
2
4 each
AC-225IP
4
4
2
1
2
AC-825IP
5
2
4 each
1
1
1
AC-825IP
8
8
4
1
4
