Introduction
Programmable Lock Strike & Auxiliary Relay release time.
Built-in Lock Strike suppressor diode.
Comes with mounting template for easier installation.
Built-in Reader Power Supply
Built-in Lock Strike Power Supply

1.2 Technical Specifications

Electrical Characteristics
Main Unit
Operating Voltage
Maximum Input Current
Battery Charger (not
tested by UL)
Outputs
Lock Strike Relay Output 5A Relay
Lock Strike Power Supply 12V DC constant voltage
Auxiliary Relay Output
Reader Power Supply
Inputs
Release to Exit (REX)
Door Monitor
Page 7
AC Input - Class 2 transformer
model PTC1640U, 16.5Vac, 40VA
(Not including attached devices)
Standby: 65mA
Maximum: 120mA
12V DC Lead Acid Battery
Up to 7AH recommended
Max Load: 1.2A
1.2 A current limit
1A Relay Closed to Ground
Max Load: 1A (AUX load & Lock
Strike not to exceed 1.2A)
Voltage: 11~12V DC
Max Current: 300mA (for a
combination of both In and Out
Readers)
N.O. Dry Contact
N.C. Dry Contact
AC-115 Hardware Installation and User's Guide
