Technical Specifications

2. Technical Specifications
Specifications
Electrical Characteristics
Power Supply Type
Operating Voltage Range
Input Current Standby (12 VDC)
Maximum Input Current (16 VDC) 110 mA
LED Control Input
Tamper Output
Cable Distance to Host Controller Up to 150 m (500 ft) using an 18 AWG
Max. Proximity Card Read Range* N/A
Proximity Card Modulation
Proximity Card Compatibility
Card Transmit Format (Reader)
Keypad Transmit Format (Reader) Programmable PIN code formats
LED Indicators
Communication
Environmental Characteristics
Operating Temperature Range
Operating Humidity Range
Outdoor Usage
AYC-Qx4 Family Installation and Programming Manual
AYC-Q54B
Linear (recommended)
5 to 16 VDC (when used as a controller,
provided by the secured intelligent
power supply)
65 mA
Dry contact N.O.
Open collector, active low, 30 mA max
sink current
cable
N/A
N/A
N/A
Two tri-colored LEDs
Data1/C1, Data0/C2 – open collector, 5
V termination
-35°C to 66°C (-31°F to 151°F)
0 to 95% (non-condensing)
Weather-resistant, meets IP65, epoxy
potted, suitable for outdoor use
AYC-Q64B
90 mA
130 mA
45 mm (1.8 in.)
ASK at 125 KHz
EM cards
Wiegand 26-Bit, or
Clock & Data
