10.2. SCANNER OPERATION

Back
Left Hand
End
Right Hand
Front
End
For reference purposes, the diagram above shows the orientation of the scanner referred to in
this manual.
Side Justified
Centre Justified
The scanner has two justification options for scanning media: side justified and centre justified.
Before scanning ensure the software is set to the correct preference and the media is inserted at
the correct position as indicated on the Paper Tray Sub-A.
Insert Media FACE UP into the scanner
NOTE: The Ci40 image is shown for illustration purposes; orientations are true for both Ci24 and Ci40 scanners
