PS User LEDs pin assignment:
Signal Name
MIO_KEY1
MIO_KEY2
Part 7：ZYNQ Programmable Logic (PL) peripherals

Part 7.1: HDMI Interface

HDMI, full name is the high definition multimedia video output interface.
AX7020 development board, differential IO of FPGA is directly connected to the
differential signal and clock of HDMI interface, realizes differential transfer of
HMDI signal in parallel and encodes and decodes in FPGA, realizes
transmission solution of DMI digital video input and output, up to 1080P@
60Hz input and output functions.
The HDMI signal is connected to the BANK34 of the PL part of ZYNQ.
Figure 7-1 is the HDMI design schematic. When the development board is
34 / 47
ZYNQ FPGA Development Board AX7020 User Manual
Figure 6-16: PS User Buttons Schematic
Figure 6-17: PS User Buttons on the FPGA Board
ZYNQ Pin Name
PS_MIO50_501
PS_MIO51_501
ZYNQ Pin Number
B13
B9
Description
PS User Button KEY1
PS User Button KEY2
