Figure 6-13: PS PMOD connector on the FPGA board
PS PMOD Connector pin assignment:
PMOD Pin
PIN1
PIN2
PIN3
PIN4
PIN5
PIN6
PIN7
PIN8
PIN9
PIN10
PIN11
PIN12

Part 6.8: User LEDs

On the AX7020 FPGA development board, two LEDs are connected to the
BANK500 IO in the PS section, and the user can use these two LEDs to debug
the program. When the BANK500 IO voltage is high, the LED light is off, and
when the BANK500 IO voltage is low, the LED will be illuminated. The
schematic diagram of the ZYNQ BANK500 IO and LEDs connections is shown
32 / 47
ZYNQ FPGA Development Board AX7020 User Manual
Signal Name
PMOD_IO0
PMOD_IO2
PMOD_IO3
PMOD_IO4
GND
+3.3V
PMOD_IO1
PMOD_IO6
PMOD_IO7
PMOD_IO5
GND
+3.3V
ZYNQ Pin Name
PS_MIO11_500
PS_MIO9_500
PS_MIO15_500
PS_MIO7_500
-
-
PS_MIO10_500
PS_MIO8_500
PS_MIO14_500
PS_MIO12_500
-
-
ZYNQ Pin Number
C6
B5
C8
D8
-
-
E9
D5
C5
D9
-
-
