Alinx FL1010 User Manual

Fmc to 2*40-pin expansion module

Advertisement

Quick Links

FMC to 2*40-Pin
Expansion Module FL1010
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FL1010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alinx FL1010

  • Page 1 FMC to 2*40-Pin Expansion Module FL1010 User Manual...
  • Page 2 FMC to 2*40-Pin Expansion Ports FL1010 User Manual Table of Contents Part1: FL1010 Module General Description..........3 Part 1.1: FL1010 Module Detail Parameter........4 Part 1.2: FL1010 Module Form Factor.......... 4 Part 2: FL1010 Module Function Description..........5 Part 2.1: FL1010 Module Block Diagram........5 Part 2.2: FMC LPC Module Pin Assignment.......
  • Page 3 The FL1010 board expands with 2 40-pin standard interfaces, a total of 68 user IOs; and 6 SMA interfaces for connecting FMC transceivers. The FMC interface of FL1010 is a standard LPC interface, used to connect to the FPGA development board, and meets the VITA57.1 standard. The connector model of FMC is: ASP_134604_01.
  • Page 4 FMC to 2*40-Pin Expansion Ports FL1010 User Manual Part 1.1: FL1010 Module Detail Parameter FL1010 module detail parameter listed as below:  LPC Connectors  2*40-Pin Expansion Ports  6 SMAs, 1 DP transmission, 1 DP receiving Part 1.2: FL1010 Module Form Factor...
  • Page 5 FMC to 2*40-Pin Expansion Ports FL1010 User Manual Part 2: FL1010 Module Function Description Part 2.1: FL1010 Module Block Diagram Figure 2-1: FL1010 Module Block Diagram as below: Figure 2-1: FL1010 Module Block Diagram Part 2.2: FMC LPC Module Pin Assignment Only the power and interface signals are listed below, and the GND signal is not listed.
  • Page 6 FMC to 2*40-Pin Expansion Ports FL1010 User Manual PIN 16 of J3 LA12_P PIN 15 of J3 LA12_N PIN 6 of J3 LA16_P PIN 5 of J3 LA16_N PIN 36 of J2 LA20_P PIN 35 of J2 LA20_N PIN 24 of J2...
  • Page 7 The Second Bit of EEPROM Address Part 2.3: 40-Pin Expansion Ports The pin definition of the 40-pin header is the same as that of the ALINX FPGA development board. PIN1, PIN37, and PIN38 are GND, PIN2 is +5V, and PIN39 and PIN40 are 3.3V; Others are IO ports, and the level standard of IO ports is determined by the FPGA development board.
  • Page 8 FMC to 2*40-Pin Expansion Ports FL1010 User Manual 8 / 8 www.alinx.com...
