Flexmike Controls and Connections

POWER/MUTE SWITCH: Press and hold to power on, press to mute, press
1.
and hold to power off. Blue light indicates mute, white light indicates talk.
MIC 1 STATUS: Lighted to indicate microphone is registered as MIC 1
2.
Solid white: Normal operation
Flashing white: Linking in progress
MIC 2 STATUS: When using a second microphone, this LED is lighted to
3.
indicate microphone is registered as MIC 2 (same behavior as MIC 1 status
light above)
EARBUD/MIC CONNECTION: Connect the earbud for monitoring for use
4.
with Pods only, also for use with optional EMA (earset) and LMA (lapel)
microphones.
CHARGING/LOW BATTERY INDICATOR: Lights red when charging, green
5.
when fully charged. When in operation, turns red to indicate low battery.
White, normal operation.
MICROPHONE VOLUME UP/DOWN
6.
USB INPUT: Connect audio source to send to 975.
7.
LANYARD INTERFACE: \Insert the lanyard into this hook to wear the
8.
Flexmike.
BATTERY: Remove the battery to replace the rechargeable battery pack
9.
9
2
3
RIGHT SIDE
5
6
LEFT SIDE
BACK
1
4
8
7
9
