System Specifications

REDCAT SPEAKER
Power output:
Acoustic frequency
response:
DC power Input:
Total harmonic distortion: <1% @ 10W
Wireless communication:
Tone control:
Audio input:
Audio output:
Integrated speaker:
Audio Link indicators:
Device Registration:
Optional battery power:
Battery life:
Dimensions (W x H x D):
Weight:
FLEXMIKE (1-2)
Description:
Earbud lanyard:
Wireless communication:
Audio distortion:
Integrated microphone:
Earbud output:
Audio input:
Volume control:
Battery power:
Battery life:
Charging:
43
USB connection:
20W
120 Hz - 13 kHz
24V / 1.75A
Access Technology (1.9 GHz + RF4CE)
1 bass/treble control
3.5mm stereo w/ volume control
3.5mm stereo w/ volume control
Exciter technology, flat-panel speaker
2 indicators for Flexmike 1 and 2
Push button for pod(s), Flexmike(s), and remote(s)
14.4V lithium ion battery pack
8 hours (fully charged)
16" x 9" x 1.75" (406 x 241 x 45mm)
2.9 lbs (1.3 kg) without battery pack
Pendant-style microphone
Magnetic clasp with integrated earbud
Access Technology (1.9 GHz)
<1%
Uni-directional electret
3.5mm
3.5mm
+/- 6 dB
2.5V NiMH battery pack
8 hours (fully charged)
2 contacts for cradle charging
Type Micro-B for charging and audio
Power: On/off switch
Registration: Push button for registration with Redcat
Dimensions (L x W x H): 2.9" x 1.1" x 1.0" (74 x 28 x 25mm)
Weight: 1.8 oz (51g)
SHAREMIKE
Description: Handheld microphone
Wireless communication: Access Technology (1.9 GHz)
Audio distortion: <1%
Integrated microphone: Uni-directional dynamic
Audio input: 3.5mm
Battery power: 2 AA NiMH battery pack
Battery life: 8 hours (fully charged)
Charging: 5V charging jack
Power: On/off button
Registration: Push button for registration with Redcat
Dimensions (L x W x H): 2.25" x 2.25" x 8.75" (57.2 x 57.2 x 222.3mm)
Weight: 7.36 oz (208.7 g)
MEDIA CONNECTOR
USB Power: 5V mini-B USB connector
Wireless communication: Access Technology (1.9 GHz + RF4CE)
Tone control: 1 bass/treble control
Audio input: 3.5mm stereo (x4) w/ master volume
Audio output: 3.5mm stereo (X2) mixed w/ volume control
Audio Link indicator: 1 LED on front panel
Registration indicator: 1 LED on back panel
Device Registration: Push button for Redcat Access
Dimensions (W x H x D): 7.6" x 5" x 1.13" (193.04 x 127 x 28.7mm)
Weight: 9.6 oz. (272.16g)
