Controls and Connections

FRONT PANEL
STATUS LIGHT: Microphone link and pair indicators
1.
Solid white: Audio link has been established
Solid blue: Indicates fixed part mode
Alternating blue/white: Registration in process
Solid white: Indicates portable part mode
Off: Unregistered or nothing linked
POWER LIGHT
2.
Solid white: Indicates power on
REAR PANEL
CARRYING HANDLE INSET
1.
CABLE MANAGEMENT AND STRAIN RELIEF
2.
WALL MOUNTING SLOTS
3.
SECURITY BRACKET SLOT
4.
COMPARTMENT FOR OPTIONAL BATTERY PACK
5.
