TRAM Module

TRAM Communication Cable

Optional Component

Cadex SMart Two+ External Battery Charger

Revision A
Equipment Overview: Optional Component
The monitor uses one TRAM module installed in the TRAM chute to
acquire patient data. The following TRAM modules are compatible, if
running software version 9B or later.
Module
TRAM 100
TRAM 200A SL
TRAM 250 A SL
TRAM 350A
TRAM 400A SL
TRAM 450A SL
TRAM 451
TRAM 451N
TRAM 451M
TRAM 500
TRAM 600 A SL
TRAM 650 A SL
TRAM 800 A SL
TRAM 850
TRAM 850 A SL
TRAM 851
TRAM 851N
TRAM 851M
The TRAM communication cable provides a communication and power
pathway between the TRAM module and the monitor.
The external battery charger can hold and charge up to two batteries.
When you select the Target Capacity switch on the charger, the
charger compares the battery's performance to a 60, 70 or 80 percent of
the target capacity set on the battery charger. If the battery fails to meet
the target performance, the battery charger will prompt you to condition
the battery. If the battery does not hold a charge, then the battery
charger will illuminate a "fail" light.
Transport Pro
2012659-042
Part Number
401174-0 _ _
T200= _
T250= _
416646-001
T400= _
T450= _
2006171-001
2006171-002
2006171-003
402593-0 _ _
T600= _
T650= _
T800SL= _
T850= _
T850SL= _
2006171-004
2006171-005
2006171-006
