Back Plastic Replacement

Back Plastic Disassembly

8-4
Disassembly: Back Plastic Replacement
The back plastic consists of the back plastic case of the monitor, the
battery housing and battery harness.
CAUTION
EQUIPMENT DAMAGE — The display assembly
components are NOT secured once you remove the
shipping bracket. ALWAYS keep the display on a flat
work surface with the TRIM KNOB control hanging over
the edge.
The back plastic is not a FRU. However, most FRU disassembly/
assembly instructions require you to remove the back plastic.
To remove the back plastic, follow this procedure.
1. Unplug the monitor from the AC power source.
2. Remove both batteries from the monitor.
3. Remove the TRAM module from the TRAM chute.
4. Remove the TRAM chute.
5. Remove the six screws from the back of the monitor.
