Controls

TRIM KNOB Control

Power Key

Function Keys

Indicators

2-8
Equipment Overview: Controls
The TRIM KNOB control is a 24-position rotary control with a push
selection switch.
NOTE
This key must be depressed for 0.25 seconds before the function is
activated. This helps prevent inadvertently turning the monitor off.
When the monitor is battery powered, this key turns the power on
and off.
When the monitor is plugged into an electrical outlet using the
optional power supply, this key turns the monitoring standby mode
on and off.
When the standby mode is turned on, patient monitoring is
discontinued. However, patient data already accumulated is retained
and the battery charging function continues.
Three fixed function keys are provided for NBP Go/Stop, Zero All, and
Silence Alarm. See the operator's manual for more information.
Power and battery indicators are located on the control panel.
Indicator
DC power
Battery power
Battery charge status
NOTE
All control panel indicators illuminate as the monitor powers up or
during changes between normal and standby mode.
Transport Pro
2012659-042
Label
A B
Revision A
