Power Cord and Plug

Recommended Tests and Checkout Procedures

Replacement or
Upgrade
Display
Front plastic
Main processor PCB
Inverter PCB and harness
Alarm light, lens, harness
and speaker
Flex circuit
TRAM
9-10
Checkout: Recommended Tests and Checkout Procedures
7. Disconnect the leakage tester from the wall receptacle.
8. Disconnect all test equipment from the device.
9. Disconnect the device power cord plug from the leakage tester power
receptacle.
Verify the power cord being used with the monitor is good. The following
are a couple of things to check for in this regard:
Failure of the power cord strain relief is very common. Often times
users of the equipment pull on the power cord itself, rather than the
power cord plug, to unplug the monitor from a wall receptacle. If in
doubt, test for continuity through each conductor of the power cord
connector and plug.
Verify line, neutral, and ground conductors are properly connected to
the power cord plug and are not short-circuited. Rewire and tighten
these, or replace the power cord, as necessary.
After re-assembling the monitor, ALWAYS complete the checkout
procedures, electrical safety tests, and regular maintenance procedures
identified and described in this manual.
Recommended Electrical Safety Tests and Checkout Procedures
Checkout Procedures
1. "Power Test" on page 9-11.
2. "Battery Function Test" on page 9-12.
3. "Video Test Screens" on page 9-13.
4. "Brightness Level Test" on page 9-13.
5. "Speaker Test" on page 9-13.
6. "TRAM Communication Test"
1. "Power Test" on page 9-11.
2. "Video Test Screens" on page 9-13.
3. "Brightness Level Test" on page 9-13.
4. "Speaker Test" on page 9-13.
1. "Power Test" on page 9-11.
2. "Speaker Test" on page 9-13.
3. "TRAM Communication Test"
1. "Power Test" on page 9-11.
2. "Battery Function Test" on page 9-12.
3. "TRAM Communication Test"
"TRAM Communication Test" on page 9-13.
Transport Pro
2012659-042
Electrical Safety Tests
on page 9-13.
1. "Ground (Earth) Integrity"
2. "Ground (Earth) Wire Leakage Current"
page 9-5.
3. "Enclosure Leakage Current"
on page 9-13.
on page 9-13.
on page 9-4.
on
on page 9-6.
