PLC Configuration
8.2

Addressing and Register Mapping

8.2.1 Data From Modbus TCP Network to Serial-Subnet
Process data offset
0x0000 — 0x001
0x0002 — 0x0003
...
0x05D8 — 0x05D9
0x05DA — 0x05DB
8.2.2 Data From Serial-Subnet to Modbus TCP Network
Process data offset
0x0000 — 0x001
0x0002 — 0x0003
...
0x05D8 — 0x05D9
0x05DA — 0x05DB
8.2.3 Idle Mode
Transaction
Enter/Exit Idle Mode
® ™
Anybus Communicator User Manual
Coil address
0x0000 — 0x000F
0x0010 — 0x001F
...
0x2EC0 — 0x2ECF
0x2ED0 — 0x2EDF
Discrete input address Input register
0x0000 — 0x000F 0x0000
0x0010 — 0x001F 0x0001
... ...
0x2EC0 — 0x2ECF 0x02EC
0x2ED0 — 0x2EDF 0x02ED
Holding Register
0x1004
84 (124)
Holding register
0x0000
0x0001
...
0x02EC
0x02ED
Holding register
0x0800
0x0801
...
0x0AEC
0x0AED
Description
Used by the Modbus TCP client to
indicate an idle/offline mode on the
network.
SCM-1202-162 1.1 en-US
