Use Cases
4. In the Frame editor Response area, add six frame fields with the following settings:
Response frame fields
Frame field
Constant
Node address
Constant
Constant
Data
Checksum
® ™
Anybus Communicator User Manual
Name
Bytes/ Type/
Length Checksum type
Function code 1 Byte
1 Byte
Node ID
Index 2 Word (two
bytes)
Sub index 1 Byte
Data 2 Byte
2 CRC
Checksum
Endianess Fixed field
Yes
N/A
N/A N/A
No
Big-endian
No
N/A
Yes
N/A
N/A N/A
SCM-1202-162 1.1 en-US
98 (124)
Value
N/A
N/A
Min 0
Max 1000
Min 0
Max 255
N/A
N/A
