CMOSTEK CMT2380F17 Manual page 65


TL5: Timer 5 Low byte Register
SFR Page = 3 Only
SFR Address = 0xCC
Bit 7
Name
R/W R/W
Reset V alue
0

TH5: Timer 5 High byte Register
SFR Page = 3 Only
SFR Address = 0xCD
Bit 7
Name
R/W R/W
Reset V alue
0
00
01
10
11
6 5
R/W R/W
0 0
6 5
R/W R/W
0 0
Rev0.1 | 65/347
Disable
INT0ET
INT2ET
KBIET
4 3
TL5 [7:0]
R/W R/W
0 0
4 3
TH5 [7:0]
R/W R/W
0 0
CMT2380F17
2 1
R/W R/W
0 0
2 1
R/W R/W
0 0
www.cmostek.com
0
R/W
0
0
R/W
0
