CMT2300A Low Power Mode Usage Guide

Summary

This paper introduces the configuration and use method of the low power consumption of CMT2300A.
The part numbers covered by this document are as shown below.
Part No.
Frequency
CMT2300A
127 - 1020MHz
Before reading this document, it is recommended that reading the《AN142 - CMT2300A Quick Start
Guideline》，that will be make it easy to understand.
Copyright © By CMOSTEK
Table1. Part Numbers Covered by This Document
Modem
(G)FSK/OOK
Rev 0.9 | Page 1/25
Function
Configuration
Transceiver
Register
AN146
AN146
Package
QFN16
www.cmostek.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMT2300A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CMOSTEK CMT2300A

Summary of Contents for CMOSTEK CMT2300A

  • Page 1: Summary

    CMT2300A Low Power Mode Usage Guide Summary This paper introduces the configuration and use method of the low power consumption of CMT2300A. The part numbers covered by this document are as shown below. Table1. Part Numbers Covered by This Document Part No.

  • Page 2: Table Of Contents

    SLP Receiving Mode Detail ......................17 2.4.1 SLP Pattern 0 ........................18 2.4.2 SLP Pattern 1~3 ......................... 19 2.4.3 SLP Pattern 4 ........................20 2.4.4 SLP Pattern 5-10 ........................ 21 2.4.5 SLP Pattern 11-13 ......................22 www.cmostek.com Rev 0.9 | Page 2/25...
  • Page 3 AN146 Document Modification Record ....................... 23 Contact Information ..........................25 www.cmostek.com Rev 0.9 | Page 3/25...

  • Page 4: Duty-Cycle Operation Mode

    RX or TX every time, if you find the CUS_SYS2 last result of the calibration 2 beyond the LFOSC_RECAL_EN (0x0D) boundary, that is not to tune the frequency by the fine adjustment, the calibration 1 can automatically run again, This calibration will www.cmostek.com Rev 0.9 | Page 4/25...
  • Page 5 Automatically exit to the preset status after transmitting,it is only valid in the packet mode. otherwise, chip will automatically exit from the TX status, but wait for the MCU to send go_* command to TX_EXIT_STATE<1:0> switch. 0：SLEEP 1：STBY 2：TFS www.cmostek.com Rev 0.9 | Page 5/25...

  • Page 6: Rx Duty-Cycle Mode

    If you use the manual switching, the automatic switching cannot be enabled. 1.2.1 Control Full Manually Controlling full manually means not opening any Duty-Cycle control. Table 4. Control Full Manually Control Bit Value SLEEP_TIMER_EN RX_DC_EN RX_TIMER_EN RX_EXIT_STATE www.cmostek.com Rev 0.9 | Page 6/25...

  • Page 7: Automatically Wake From Sleep

    Open the RX_DC_EN, when the chip automatically wakes from SLEEP, it will not jump to STBY, but will directly do the PLL correction and switch to the RX to receive. In this mode, the RFS status is not allowed, and the MCU participation has been greatly reduced. www.cmostek.com Rev 0.9 | Page 7/25...

  • Page 8: Automatically Wake From Sleep, Automatically Exit From Rx

    SLEEP_TIMER_EN = 1 SLEEP STBY RX_TIMER_EN = 1, RX_EXIT_STATE = 2 RX_TIMER_EN = 1, RX_EXIT_STATE = 1 RX_TIMER_EN = 1, RX_EXIT_STATE = 0 Figure 5. Receiver Automatically Wakes from SLEEP, Automatically Exits from RX www.cmostek.com Rev 0.9 | Page 8/25...

  • Page 9: Receive Full Automatically

    FIFO reading at RX. The first thing to note about MCU and CMT2300A cooperation is to obey the operation rule. Once the automatic controlling is enabled, you can't manually order to do the same status switching. Also, it is important to note that if the automatic exiting from RX is enabled and the exit status is SLEEP, then the interrupt status in the control bank2 will be lost after exiting to SLEEP.

  • Page 10: Automatically Exit From Tx

    Table 10. Automatically Wake from SLEEP, Automatically Exit from TX Control Bit Value SLEEP_TIMER_EN TX_DC_EN TX_EXIT_STATE 0/1/2 SLEEP_TIMER_EN = 1 SLEEP STBY TX_EXIT_STATE = 2 TX_EXIT_STATE = 1 TX_EXIT_STATE = 0 Figure8. Transmitter Automatically Wakes from SLEEP, Automatically Exits from TX www.cmostek.com Rev 0.9 | Page 10/25...

  • Page 11: Transmit Full Automatically

    100% reliable mechanism to make the chip to stop running and switch back to the manual control mode. Assuming CMT2300A starts the full-automatic Duty-Cycle operation after the initialization configuration introduced above, the MCU can exit safely by operating the following register bits: www.cmostek.com...
  • Page 12 So in general, it's OK to let users use the first method to exit. The second one is used when there is a special requirement. It is important to note that the two mechanisms that exit from the full-automatic Duty-Cycle mode must be operated only after the CMT2300A has entered the full-automatic Duty-Cycle mode, otherwise an operation error occurs.

  • Page 13: Supper Low Power(Slp) Receiving Mode

    AN146 Supper Low Power(SLP) Receiving Mode CMT2300A provides a series of options to help users to achieve the supper low power (SLP) reception under the different application requirements. These options must be valid when RX_TIMER_EN is set to 1, that is, when the RX timer is valid. The core content of SLP receiver is how to let the receiver minimize the RX time without the signal, and appropriately extend the RX time to receive with the signal.

  • Page 14: Channel Sensing

    (1 indicates the presence of the signal and 0 indicates noise). This signal is not only output to the GPIO as an interrupt, but also to assist the implementation of the SLP as a trigger condition. There are two mechanisms for channel sensing, namely, PJD (Phase Jump Detector) and RSSI contrast. www.cmostek.com Rev 0.9 | Page 14/25...

  • Page 15: Register Associated With Channel Sensing

    Table 15. Register Located in the Configuration Bank Register Bits Bit Name Function Description Name PJD_TH_SEL PJD's hidden configuration bit can be fixed to 0. CUS_SYS11 Channel sensing mode option: (0x16) CCA_INT_SEL<1:0> 0： Determine whether there is a signal by PJD's www.cmostek.com Rev 0.9 | Page 15/25...

  • Page 16: Rssi Contrast

    The following chapter will discuss how the RSSI_VLD signal assists to implement the supper low power (SLP) receiving mode. In general, the more times the PJD inverts, the more reliable the judgment is; the less it www.cmostek.com Rev 0.9 | Page 16/25...

  • Page 17: Slp Receiving Mode Detail

    SLP modes in different RX Duty-Cycle modes. These 14 SLP patterns are explained in detail below. First of all, we assume that CMT2300A is working in the RX Duty-Cycle mode, automatically waking from SLEEP, automatically exiting from RX and switching to STBY, MCU is responsible for switching from STBY to SLEEP, and switching from STBY to RX.

  • Page 18: Slp Pattern 0

    Using the RSSI_VLD generated by the PJD to assist the supper low power reception is an innovation of CMT2300A. The effect is very significant. Users are strongly recommended for use. Option 3 combines the RSSI_VLD generated by PJD and PREAM_OK to make the judgment term. It adds the reliability and doesn't add much time.

  • Page 19: Slp Pattern 1~3

    AN146 diagram below, the MCU is only responsible for sending go_rx and go_sleep command switching the status. CMT2300A will perform to automatically wake from sleep and automatically exit from RX, and generate the corresponding interrupt. The time of RX and SLEEP, etc. given in the figure is only for illustration, without any special meaning.

  • Page 20: Slp Pattern 4

    It is with very high reliability. The minimum value of RX_PREAM_SIZE for CMT2300A can be set to 4 symbols. If combined with the RSSI_VLD signal, it will not increase the time of RX T1, but also can achieve the more reliable detection result.

  • Page 21: Slp Pattern 5-10

    操作 RX T1 RX T2 SLEEP STBY CAL STBY SLEEP (10 ms) (100 ms) CMT2300A 行为 SL_TMO PREAM_OK有效 PKT_OK有效 RX_TMO Figure19. SLP Pattern 4 The user needs to set the RX T2 long enough to receive all the content needed.

  • Page 22: Slp Pattern 11-13

    RX T1 RX T2 SLEEP STBY CAL RX (等待MCU操作) STBY SLEEP (10 ms) (30 ms) CMT2300A 行为 SL_TMO PREAM_OK有效 SYNC_OK有效 PKT_OK Figure20. SLP Pattern 11-13 The following scenes are more suitable for using pattern 11 to pattern 13: For the application with Preamble and Sync Word in the packet, you can use the 3 patterns. These 3...
  • Page 23 AN146 3. Document Modification Record Table18. Document Modification Record Sheet Version Chapter Modification descriptions Date Initial release 2017-08-11 www.cmostek.com Rev 0.9 | Page 23/25...
  • Page 24 Cmt2300_WriteReg(CMT2300_CUS_SYS2, 0xFA); /* PJD_TH_SEL = 1 */ tmp = Cmt2300_ReadReg(CMT2300_CUS_SYS11); tmp |= 0x80; Cmt2300_WriteReg(CMT2300_CUS_SYS11, tmp); /* VCO_PKD_CTL_CODE = 1 */ tmp = Cmt2300_ReadReg(CMT2300_CUS_CMT3); tmp &= 0x3F; tmp |= 0x40; Cmt2300_WriteReg(CMT2300_CUS_CMT3, tmp); Cmt2300_EnableReadFifo(); else Cmt2300_WriteReg(CMT2300_CUS_SYS2, 0x00); www.cmostek.com Rev 0.9 | Page 24/25...
  • Page 25 The material contained herein is the exclusive property of CMOSTEK and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of CMOSTEK. CMOSTEK products are not authorized for use as critical components in life support devices or systems without express written approval of CMOSTEK.
