35 Packaging Information

The packaging information of the CMT2380F17 is shown in the below figure.
40
1
2
Top View
Side View
Symbol
h
D
Figure 35-1. QFN40 5x5 Packaging
Table 35-1. QFN40 5x5 Packaging Scale
Min.
A 0.70
A1 0
b 0.15
b1
C 0.18
D 4.90
D2 3.60
e
Ne
Nd
E 4.90
E2 3.60
L 0.35
L1
K 0.20
0.30
Rev0.1 | 343/347
b
EXPOSED THERMAL
PAD ZONE
Scale (mm)
Maximum
Typ.
0.75
0.02
0.20
0.14REF
0.20
5.00
3.70
0.40 BSC
3.60 BSC
3.60 BSC
5.00
3.70
0.40
0.10REF
-
0.35
CMT2380F17
e
40
1
2
D2
N
d
Bottom View
Max.
0.80
0.05
0.25
0.25
5.10
3.80
5.10
3.80
0.45
-
0.40
www.cmostek.com
L
K
