15.7 Interrupt Register


TCON：Timer/Counter Control Register
SFR Page = 0~F
SFR Address = 0x88
Bit 7
Name TF1
R/W R/W
Reset V alue 0
Bit 3: IE1, Interrupt 1 (nINT1) Edge flag.
0: Cleared when interrupt processed on if transition-activated.
1: Set by hardware when external interrupt 1 (nINT1) edge is detected (transmitted or level-activated).
Bit 2: IT1: Interrupt 1 (nINT1) Type control bit.
0: Cleared by software to specify low level triggered external interrupt 1 (nINT1). If INT1H (AUXR0.1) is
set, this bit specifies high level triggered on nINT1.
1: Set by software to specify falling edge triggered external interrupt 1 (nINT1). If INT1H (AUXR0.1) is set,
this bit specifies rising edge triggered on nINT1.
Bit 1: IE0, Interrupt 0 (nINT0) Edge flag.
0: Cleared when interrupt processed on if transition-activated.
1: Set by hardware when external interrupt 0 (nINT0) edge is detected (transmitted or level-activated).
Bit 0: IT0: Interrupt 0 (nINT0) Type control bit.
0: Cleared by software to specify low level triggered external interrupt 0 (nINT0). If INT0H (AUXR0.0) is
set, this bit specifies high level triggered on nINT0.
1: Set by software to specify falling edge triggered external interrupt 0 (nINT0). If INT0H (AUXR0.0) is set,
this bit specifies rising edge triggered on nINT0.

IE：Interrupt Enable Register
SFR Page
SFR Address = 0xA8
Bit
7
Name EA
R/W R/W
Reset V alue 0
6 5
TR1 TF0
R/W R/W
0 0
= 0~F
6 5
EDMA ET2
R/W R/W
0 0
4 3
TR0 IE1
R/W R/W
0 0
4 3
ES0 ET1
R/W R/W
0 0
Rev0.1 | 120/347
CMT2380F17
2 1
IT1 IE0
R/W R/W
0 0
2 1
EX1 ET0
R/W R/W
0 0
www.cmostek.com
0
IT0
R/W
0
0
EX0
R/W
0
