AUXR8： Auxiliary Register 8
SFR Page = 5 only
SFR Address = 0xA4
Bit 7
Name POE7
R/W
R/W
Reset V alue 1
Bit 7: POE7, PCA0 PWM7 main channel (PWM7O) output control.
0: Disable PWM7O output on port pin.
1: Enable PWM7O output on port pin. Default is enabled.
Bit 6: POE6, PCA0 PWM6 main channel (PWM6O) output control.
0: Disable PWM6O output on port pin.
1: Enable PWM6O output on port pin. Default is enabled.
Bit 5: C0PPS2, {PWM6, PWM7} Port pin Selection 2.
Bit 3: KBI0PS0, KBI0~1 Port pin Selection 0.
Bit 2: S1COPS, S1BRG Clock Output (S1CKO) port pin Selection.

AUXR9: Auxiliary Register 9
SFR Page = 6 only
SFR Address = 0xA4
Bit 7
Name --
R/W
W
Reset V alue 0
6 5
POE6 C0PPS2
R/W R/W
1 0
C0PPS2
0
1
KBI0PS0
0
1
S1COPS
0
1
6 5
-- T1G1
W R/W
0 0
Rev0.1 | 330/347
4 3
-- KBI0PS0
W R/W
0 0
PWM6 PWM7
P6.0 P6.1
P3.0 P3.1
KBI0 KBI1
P1.0 P1.1
P4.7 P3.3
S1CKO
P4.7
P6.1
4 3
T0G1 C0FDC1
R/W R/W
0 0
CMT2380F17
2 1
S1COPS --
R/W W
0 0
2 1
C0FDC0 S1PS1
R/W R/W
0 0
www.cmostek.com
0
--
W
0
0
S1PS0
R/W
0
