CMOSTEK CMT2380F17 Manual

Ultra Low Power Sub-1GHz Wireless MCU

MCU Features


1-T 80C51 CPU platform

16kB program area Flash with password access
protects. Default space configuration:
-
AP program space (13.5 kB, 0000h ~ 35FFh)
-
IAP data space (1.0 kB, 3600h ~ 39FFh)
-
ISP boot code space (1.5 kB, 3A00h ~ 3FFFh)

1 kB data memory
-
256-byte high-speed buffer
-
768-byte of extended RAM (XRAM)
-
Extended RAM (XRAM) supporting page access

On-chip debug interface (OCD)

Multiple power control modes: power-down mode, idle
mode, slow-frequency mode, sub-frequency mode,
RTC mode, watch mode, and monitor mode
-
All interrupts supporting to wake up the CPU
from IDLE mode
-
10 interrupt sources supporting to wake up the
CPU in power-down mode
-
Slow-frequency mode and sub-frequency mode
supporting low-speed MCU operation
-
RTC mode supporting real-time clock (RTC) to
wake up the CPU in power-down mode
-
Watch mode supporting watchdog (WDT) to
wake up the CPU in power-down mode
-
Monitor mode supporting BOD1 to wake up the
CPU in power-down mode

Operating frequency range: up to 25 MHz
-
External crystal oscillator mode, 0–12 MHz at
2.0–3.6 V and 0–25 MHz at 2.4–3.6 V
-
CPU operating frequency can reach 12 MHz at
1.8-3.6 V and 25 MHz at 2.2-3.6 V
-
When on-chip clock frequency multiplier (CKM)
is at 2.7–3.6 V, the CPU operating frequency
can reach 36 MHz.

Double data pointer

Interrupt control
-
16 interrupt sources, 4 priority levels
-
3 external interrupts nINT0/1/2, with filtering
-
All external interrupts supporting high/low or
rising/falling edge triggering

8-channel 12-bit single-ended ADC with a sampling
rate greater than 500 ksps
Copyright © By CMOSTEK
CMT2380F17

1 master/slave SPI serial interface, the rate reaching 12 MHz

2 master/slave two-wire serial interfaces: TWI0/I2C0
and STWI (SI2C)

1-channel DMA engine
-
P2P, M2P, P2M
-
Memory target: XRAM
-
Peripheral targets: UART0, UART1, SPI,
TWI0/I2C0, ADC12 and CRC16
-
Timer 5 and Timer 6 are applied by DMA; they
are independent timers when DMA is not
enabled.

Totally 9/11 timers/counters on-chip
-
RTC timer and WDT timer
-
Timer 0, 1, 2, 3
-
PCA0, programmable counter array 0
-
S0BRG and S1BRG
-
When timer 2/3 is used in separated mode,
there are a total of 11 timers

8 keyboard interrupts

1 enhanced UART0 and 1 normal UART1

RF Features


Operating frequency: 127-1020 MHz

Modulation and demodulation methods: (G)FSK,
(G)MSK, OOK

Data rate: 0.5-300 kbps

Sensitivity: -121 dBm @ 434 MHz, FSK

Receive current: 8.5 mA @ 434 MHz, FSK

Transmitting current: 72 mA @ 20 dBm, 434 MHz

Configurable FIFO up to 64-Byte

System Features

 Operating voltage: 1.8 – 3.6 V
Operating temperature: -40 – 85 ℃


QFN40 5x5 packaging

Application


Automatic meter reading

Home security and building automation

Wireless sensor networks and industrial monitoring

ISM band data communication
Rev0.1 | 1/347
